SKU: Patch Cord SS-OP-D-LC-M-20 Kategori: Taggar: , ,

Beskrivning

Patch Cord SS-OP-D-LC-M-20 is Fiber Patch Cable wtth LC/PC,LC/PC,Multi-mode,20m,A1b,2mm

Patch Cord SS-OP-D-LC-M-20 Product Overview

Optical fibers are used for carrying signals on Gigabit networks or networks with higher packet rates. An optical fiber is a carrier of optical signals and transmits optical signals over a short distance.
In the latest cabling infrastructure of ISO/IEC 11801, multimode fibers are classified into four categories: OM1, OM2, OM3, and OM4.
OM1: traditional 62.5/125 μm multimode fibers. OM1 fibers have a large core diameter and numerical aperture, and provide high light gathering ability and bending resistance.
OM2: traditional 50/125 μm multimode fibers. OM2 fibers have a small core diameter and numerical aperture. Compared with OM1 fibers, OM2 fibers provide higher bandwidth because they significantly reduce the modal dispersion. When transmitting data at 1 Gbit/s with 850 nm wavelength, OM1 and OM2 fibers support maximum link lengths of 220 m and 550 m, respektive. OM1 and OM2 fibers can provide sufficient bandwidth within a distance of 300 m. Generally, OM1 and OM2 fibers are orange, as shown in Figure 5-5.
OM3: new-generation multimode fibers, with longer transmission distances than OM1 and OM2 fibers.
OM4: laser optimized multimode fibers with 50 μm core diameter. OM4 is an improvement to OM3 and only increases the modal bandwidth. OM4 fibers provide 4700 MHz*km of modal bandwidth, whereas OM3 fibers provide only 2000 MHz*km of modal bandwidth. Generally, OM3 and OM4 fibers are light green. You can identify OM3 and OM4 fibers by their labels or printed marks.

Patch Cord SS-OP-D-LC-M-20 Product Pictures

Patch Cord optic fiber cable ycictPatch Cord SS-OP-D-LC-M-20 20m optic cord

Patch Cord SS-OP-D-LC-M-20 fiber cable 20m 30m 50mPatch Cord SS-OP-D-LC-M-20 UPC Multi mode

Patch Cord SS-OP-D-LC-M-20 Product Specifications

Anslutningstyp LC UPC to LC UPC
Fiber Grade Bend Insensitive
Fiber Count Duplex
Fiber Mode OM3 50/125μm
Våglängd 850/1300nm
10G Ethernet Distance 300m at 850nm
Insättningsförlust ≤0.3dB
Return Loss ≥30dB
Min. Bend Radius (Fiber Core) 7.5mm
Min. Bend Radius (Fiber Cable) 20/10D (Dynamic/Static)
Attenuation at 850nm 3.0dB/km
Attenuation at 1300nm 1.0dB/km
Cable Jacket Riser (OFNR)
Cable Outside Diameter (OD) 2.0mm
Polarity A (Tx) to B (Rx)
Drifts-/förvaringstemperatur Drift: -20 till 70°C (-4 to 158℉)

Lagring: -40 to 80℃ (-40 to 176℉)

Typ Transmission Mode Anslutning
On the USG6000E On the peer device
LC/PC-LC/PC Single-mode/Multi-mode LC/PC LC/PC
LC/PC-SC/PC SC/PC
LC/PC-FC/PC FC/PC
MPO/PC-MPO/PC Multi-mode MPO/PC MPO/PC

Patch Cord SS-OP-D-LC-M-20 Product And More Fiber Cables

Beskrivning Artikelnummer Modell Kontakt X1 Kontakt X2 Kabellängd Bend radius
Kablage,SC/PC,SC/PC,Singelläge,5m,G.652D,3mm 14130098 SS-OP-D-SC-S-5 SC/PC SC/PC 5 m 30 mm
Kablage,LC/PC,SC/PC,Singelläge,5m,G.652D,2mm 14130193 SS-OP-LC-SC-S-5 LC/PC SC/PC 5 m 30 mm
Kablage,LC/PC-LC/PC,Singlemode,G.652D,2mm,5m 14130195 SS-OP-D-LC-S-5 LC/PC LC/PC 5 m 30 mm
Kablage,LC/PC,SC/PC,Singelläge,10m,G.652D,2mm 14130196 SS-OP-LC-SC-S-10 LC/PC SC/PC 10 m 30 mm
Kablage,LC/PC,FC/PC,Singelläge,10m,G.652D,2mm 14130197 SS-OP-LC-FC-S-10 LC/PC FC/PC 10 m 30 mm
Kablage,LC/PC,LC/PC,Singelläge,10m,G.652D,2mm 14130199 SS-OP-D-LC-S-10 LC/PC LC/PC 10 m 30 mm
Kablage,LC/PC,FC/PC,Multi-mode,10m,A1b,2mm 14130221 SS-OP-LC-FC-M-10 LC/PC FC/PC 10 m 30 mm
Kablage,LC/PC,LC/PC,Multi-mode,10m,A1B,2mm 14130222 SS-OP-D-LC-M-10 LC/PC LC/PC 10 m 30 mm
Kablage,LC/PC,SC/PC,Multi-mode,10m,A1b,2mm 14130223 SS-OP-LC-SC-M-10 LC/PC SC/PC 10 m 30 mm
Optical adapter-LC/PC-LC/PC-Blue-Shell:Plastic-Sleeve:Zirconia-Square 14130248 QW1P0FIBER06 LC/PC LC/PC – –
Kablage,LC/PC,LC/PC,Singelläge,20m,G.652D,2mm 14130251 SS-OP-D-LC-S-20 LC/PC LC/PC 20 m 30 mm
Kablage,LC/PC,SC/PC,Multi-mode,30m,A1b,2mm 14130275 SS-OP-LC-SC-M-30 LC/PC SC/PC 30 m 30 mm
Kablage,LC/PC,SC/PC,Singelläge,30m,G.652D,2mm 14130276 SS-OP-LC-SC-S-30 LC/PC SC/PC 30 m 30 mm
Kablage,LC/PC,SC/PC,Multi-mode,20m,A1b,2mm 14130279 SS-OP-LC-SC-M-20 LC/PC SC/PC 20 m 30 mm
Kablage,LC/PC,SC/PC,Singelläge,20m,G.652D,2mm 14130280 SS-OP-LC-SC-S-20 LC/PC SC/PC 20 m 30 mm
Kablage,LC/PC,LC/PC,Multi-mode,20m,A1b,2mm 14130295 SS-OP-D-LC-M-20 LC/PC LC/PC 20 m 30 mm
Kablage,LC/PC,LC/PC,Multi-mode,5m,A1b,2mm 14130296 SS-OP-D-LC-M-5 LC/PC LC/PC 5 m 30 mm
Kablage,LC/PC,SC/PC,Multi-mode,50m,A1b,2mm 14130311 SS-OP-LC-SC-M-50 LC/PC SC/PC 50 m 30 mm
Kablage,LC/PC,SC/PC,Singelläge,50m,G.652D,2mm 14130312 SS-OP-LC-SC-S-50 LC/PC SC/PC 50 m 30 mm
Kablage,LC/PC,LC/PC,Singelläge,6m,G.652D,2mm 14130360 SS-OP-D-LC-S-6 LC/PC LC/PC 6 m 30 mm
Optical Cable Parts,MPO/PC,MPO/PC,MULTI-MODE,2m,8 CORES,0m/0m,GJFH-8A1A.2(OM3),3.5MM,LSZH,43MM SHORT MPO,BENDING INSENSITIVE 14130823 F00MPMP01 MPO/PC MPO/PC 2 m 18 mm
Optical Cable Parts,MPO/PC,MPO/PC,Multimode(OM3,Bending Insensitive),30m,8 Kärnor,0m/0m,GJFH 8A1a,3.5mm,LSZH,42mm Short MPO,Inomhus 14130823-002 FMMM03001 MPO/PC MPO/PC 30 m 17.5 mm
Optical Cable Parts,MPO/PC,MPO/PC,Multimode(OM3,Bending Insensitive),100m,8 Kärnor,0m/0m,GJFH 8A1a,3.5mm,LSZH,42mm Short MPO,Inomhus 14130823-003 FMMM10001 MPO/PC MPO/PC 100 m 17.5 mm
Optical Cable Parts,MPO/PC,MPO/PC,MULTI-MODE,15m,8 CORES,0m/0m,GJFH-8A1A.2(OM3),3.5MM,LSZH,60mm MPO,Bending insensitive 14130923 SS-OP-D-MPO12-M-15 MPO/PC MPO/PC 15 m 18 mm
Optical Cable Parts,MPO/PC,MPO/PC,Multi-mode,10m,8 kärnor,GJFH-8A1a.3(OM4),3.5mm,0mm,LSZH,Bending Insensitive 14134486 MPO12-MPO12-M4-10 MPO/PC MPO/PC 10 m
LC/UPC LC/APC SC/UPC SC/APC FC/APC FC/UPC ST/UPC LSH/APC MTR/UPC
G.657.A1 G.657.A2 G.652.D BIF G.651

Patch Cord SS-OP-D-LC-M-20 Product Features

  • Low insertion loss and high return loss
  • Easy to handle
  • Stable environment
  • High performance and cost effective

Patch Cord SS-OP-D-LC-M-20 Product Applications

  • Telecommunications
  • LAN
  • FTTH
  • Optic fiber sensors
  • Testing instruments

Patch Cord SS-OP-D-LC-M-20 Product Topology

Patch Cord SS-OP-D-LC-S-20 topology
