Opis
Quectel EG95-NAXD LGA Module is LTE Cat 4 module in LGA package optimized specially for M2M and IoT applications with maximum data rates up to 150 Mbps downlink and 50 Mbps uplink
Quectel EG95-NAXD LGA Module Product Overview
Quectel EG95-NAXD LGA Module is LTE Cat 4 module in LGA package delivering maximum data rates up to 150 Mbps downlink and 50 Mbps uplink. The module is pin-to-pin compatible with Quectel GSM M95 module, UMTS/HSPA UG95/UG96 modules and LPWA BG95 series/BG96/BC95-G modules. And it is backward-compatible with existing GSM/GPRS & UMTS/HSPA(+) omrežja, and provides a rich set of Internet protocols, industrijski standardni vmesniki in številne funkcionalnosti (USB serial drivers for Windows 7/8/10, Linux, Android). EG95 series contains 6 različice: EG95-NA, EG95-NAX, EG95-NAXD, EG95-E, EG95-EX and EG95-AUX
Quectel EG95-NAXD LGA Module Product Pictures
Quectel EG95-NAXD LGA Module Product Specifications
| Znamka | Quectel |
| LTE kat 4 | EG95-NAXD (Samo podatki) |
| Regija/operater | Severna Amerika |
| Dimenzije (mm) | 29.0 × 25.0 × 2.3 |
| delovna temperatura | -35 do +75 °C |
| Extended Temperature | -40 do +85 °C |
| LTE-FDD | B2/B4/B5/B12/B13/B25/ B26 |
| WCDMA | B2/B4/B5 |
| GSM/EDGE | / |
| GNSS | GPS/GLONASS/BeiDou/ Galileo/QZSS (Neobvezno) |
| Nosilec | Amerika: Verizon*/ |
| AT&T*/T-Mobile*/Sprint* | |
| Regulativni | Globalno: GCF |
| Amerika: FCC*/PTCRB* | |
| drugi | WHQL/RoHS |
| Hitrost prenosa podatkov LTE-FDD (Mb/s) | 150 (DL)/50 (UL) |
| Hitrost prenosa podatkov DC-HSPA+ (Mb/s) | 42 (DL)/5.76 (UL) |
| Hitrost prenosa podatkov WCDMA (kbps) | 384 (DL)/384 (UL) |
| EDGE Data Rate (kbps) | / |
| GPRS Data Rate (kbps) | / |
| (U)SIM | x 2 |
| UART | x 2 |
| USB 2.0 | x 1 |
| Audio Digital (PCM) | x 1 |
| 2C | x 1 |
| NETLIGHT | x 1 |
| SPI | x 1 |
| Glavna antena | x 1 |
| Rx-diversity Antenna | x 1 |
| GNSS antena | x 1 |
| PWRKEY | x 1 |
| RESET_N | x 1 |
| USB_BOOT | x 1 |
| Načini govornega kodeka | / |
| Echo aritmetika | / |
| Avdio | / |
| DTMF | / |
| DFOTA | ● |
| QMI/RmNet | ● |
| MIMO 2 x 2 | ● |
| Audio Playback*/Audio Record- | Neobvezno |
| QuecOpen® | / |
| QuecLocator® | ● |
| QuecFile | ● |
| (U)Zaznavanje kartice SIM | ● |
| USB serijski gonilnik | Windows 7/8/8.1/10, |
| Linux 2.6–5.4, | |
| Android 4.x–9.x | |
| Gonilnik GNSS | Android 4.x–9.x |
| Voznik RIL | Android 4.x–10.x |
| Gonilnik NDIS | Windows 7/8/8.1/10 |
| gonilnik GobiNet | Linux 2.6–5.4 |
| Gonilnik QMI_WWAN | Linux 3.4–5.4 |
Quectel EG95-NAXD LGA Module Product Features
- LTE category 4 modul, optimiziran za aplikacije M2M in IoT
- Multi-band LTE, UMTS/HSPA(+) in pokritost GSM/GPRS/EDGE
- Compact SMT form factor ideal for size-constrained applications with extended operation temperature range
- Embedded power management unit (PMU) featuring ultra-low deep-sleep current consumption
- Simple migration from 2G/3G to 4G with a flexible and scalable platform
- LTE kat 4 modul
- 0mm × 25.0mm × 2.3mm
- LGA package
- SMT form factor
- downlink 150Mbps / uplink 50Mbps
- Razširjeno temperaturno območje od -40°C do +85°C
Quectel EG95-NAXD LGA Module and More Models
Quectel EG95-NA LTE kat 4 module LGA package
Quectel EG95-NAX LTE kat 4 module LGA package
Quectel EG95-NAXD (Samo podatki) LTE kat 4 module LGA package
Quectel EG95-E LTE kat 4 module LGA package
Quectel EG95-EX LTE kat 4 module LGA package
Quectel EG95-AUX LTE kat 4 module LGA package
Quectel EG95-NAXD LGA Module Product Applications
