SKU: Huawei S5735-S24T4XEZ-V2 Switch Kategorija: Oznake: , ,

Opis

Huawei S5735-S24T4XEZ-V2 Switch is a standard gigabit Ethernet switch with 24×10/100/1000Base-T ports, 4×10 GE SFP+ vrata, 2x12GE stack ports and 1+1 power supply backup. It provides GE electrical & 2.5GE optical downlink ports, 10GE uplink ports and one extended slot

Huawei S5735-S24T4XEZ-V2 Switch Product Overview

The switch offers Forwarding performance: 132 Mpps and Switching capacity: 176 Gbps/520 Gbps. It is developed based on next-generation high-performing hardware and software platform. S5735-S-V2 switches support simplified operations and maintenance (O&M), and flexible Ethernet networking. It also provides enhanced Layer 3 funkcije in zrele funkcije IPv6. S5735-S24T4XEZ-V2 can be used in various scenarios. Na primer, it can be used as an access or aggregation switch on a campus network or as an access switch for Metropolitan Area Network.

Huawei S5735-S24T4XEZ-V2 Switch Product Pictures

Huawei S5735-S24T4XEZ-V2 Switch S5735-SHuawei S5735-S24T4XEZ-V2 Switch S5735-S switch

Huawei S5735-S24T4XEZ-V2 Switch datasheetHuawei S5735-S24T4XEZ-V2 Switch S5735

Huawei S5735-S24T4XEZ-V2 Switch Product Specifications

Model izdelka S5735-S24T4XEZ-V2 S5735-S24P4XEZ-V2 S5735-S48T4XEZ-V2 S5735-S48P4XEZ-V2 S5735-S48T4XE-XA-V2
Posredovanje uspešnosti 132 poslanci 132 poslanci 168 poslanci 168 poslanci 168 poslanci
Preklopna zmogljivost2 176 Gbps/520 Gbps 176 Gbps/520 Gbps 224 Gbps/520 Gbps 224 Gbps/520 Gbps 224 Gbps/520 Gbps
Fiksna vrata 24 x 10M/100M/1000M Base-T ports, 4 x 10GE SFP+ ports , 2 x 12GE stack ports 48 x 10M/100M/1000M Base-T ports , 4 x 10GE SFP+ ports +, 2 x 12GE stack ports
PoE – Podprto, PoE+ – Podprto, PoE+ –
Vrsta napajanja 1+1 power supply backup 3 x power modules, N+1 power supply backup 1+1 power supply backup 3 x power modules, N+1 power supply backup 2 x built-in AC power modules, 1+1 power supply backup
Expansion Slots One expansion slot –
Funkcije MAC MAC address auto-learning and aging
Statično, dinamično, in vnose naslovov MAC blackhole
Filtriranje paketov na podlagi izvornih naslovov MAC
Interface-based MAC address learning limiting
VLAN 4094 VLAN
Glasovni VLAN
MUX VLAN
Dodelitev VLAN na podlagi naslovov MAC, protokoli, podomrežja IP, pravila, in pristanišča
Usmerjanje IP Statična pot, RIPv1/v2, RIPng, OSPF, OSPFv3, ECMP, JE-JE, IS-ISv6, BGP, BGP4+, VRRP, and VRRP6
Interoperabilnost VBST (združljiv s PVST/PVST+/RPVST)
LNP (podobno kot DTP)

Huawei S5735-S24T4XEZ-V2 Switch Product Features

  • S5735-S-V2 supports a broad set of Layer 2/Layer 3 multicast protokoli, such as PIM SM, PIM DM, PIM SSM, in vohljanje IGMP. This capability is ideal for high-definition video backhaul and video conferencing access.
  • S5735-S-V2 provides multiple Layer 3 funkcije, vključno z OSPF, JE-JE, BGP, in VRRP, srečanja podjetij’ access and aggregation service needs and enabling a variety of voice, video, in podatkovne aplikacije.
  • 5735-S-V2 supports MAC address authentication, 802.1X authentication, in izvaja dinamično izvajanje politik (VLAN, QoS, in ACL) uporabnikom.
  • S5735-S-V2 provides a series of mechanisms to defend against DoS attacks and user-targeted attacks. Napadi DoS so usmerjeni na stikala in vključujejo poplavo SYN, Zemljišče, Smrkec, in napadi poplav ICMP. Napadi, usmerjeni na uporabnike, vključujejo lažne napade na strežnik DHCP, Ponarejanje naslovov IP/MAC, Poplava zahtev DHCP, and changing of the DHCP CHADDR value.

Huawei S5735-S24T4XEZ-V2 Switch and More Models

S5735-S24T4XE-V2 24 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports 1+1 power supply backup

S5735-S24T4XEZ-V2 24 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports One extended slot 1+1 power supply backup

S5735-S24P4XE-V2 24 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports 3 napajalniki, N+1 power supply backup PoE+

S5735-S24P4XEZ-V2 24 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports One extended slot 3 napajalniki, N+1 power supply backup PoE+

S5735-S24U4XE-V2 24 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports 3 napajalniki, N+1 power supply backup PoE++(90W)

S5735-S24T8J4XE-XA-V2 24 x 10/100/1000Base-T vrata, 8 x 2.5 GE SFP+ vrata(or 2*10GE SFP+ ports), 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports Built-in dual AC power, 1+1 power supply backup

S5735-S24T8J4XEZ-V2 24 x 10/100/1000Base-T vrata, 8 x 2.5 GE SFP+ vrata(or 2*10GE SFP+ ports), 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports One extended slot 1+1 power supply backup

S5735-S24P8J4XEZ-V2 24 x 10/100/1000Base-T vrata, 8 x 2.5 GE SFP+ vrata(or 2*10GE SFP+ ports), 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports One extended slot 3 napajalniki, N+1 power supply backup

S5735-S48T4XE-V2 48 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports 1+1 power supply backup

S5735-S48T4XE-XA-V2 48 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports Built-in dual AC power, 1+1 power supply backup

S5735-S48T4XEZ-V2 48 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports One extended slot 1+1 power supply backup

S5735-S48P4XE-V2 48 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports 3 napajalniki, N+1 power supply backup PoE+

S5735-S48P4XEZ-V2 48 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports One extended slot 3 napajalniki, N+1 power supply backup PoE+

S5735-S48U4XE-V2 48 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports 3 napajalniki, N+1 power supply backup PoE++(90W)

Huawei S5735-S24T4XEZ-V2 Switch Ordering Info

Model Opis izdelka
CloudEngine S5735S24T4XE-V2 CloudEngine S5735-S24T4XE-V2 (24 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports, brez napajalnega modula)
CloudEngine S5735S24T4XEZ-V2 CloudEngine S5735-S24T4XEZ-V2 (24*10/100/1000vrata BASE-T, 4*10GE SFP+ vrata, 2*12GE stack ports, expansion card slot, brez napajalnega modula)
CloudEngine S5735S24P4XE-V2 CloudEngine S5735-S24P4XE-V2 (24 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports, PoE+, brez napajalnega modula)
CloudEngine S5735S24P4XEZ-V2 CloudEngine S5735-S24P4XEZ-V2 (24*10/100/1000vrata BASE-T (PoE+), 4*10GE SFP+ vrata, 2*12GE stack ports, expansion card slot, brez napajalnega modula)
CloudEngine S5735S24U4XE-V2 CloudEngine S5735-S24U4XE-V2 (24 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x12GE stack ports, PoE++, brez napajalnega modula)
CloudEngine S5735S24T8J4XE-XA-V2 CloudEngine S5735-S24T8J4XE-XA-V2 (24*10/100/1000vrata BASE-T, 8*2.5GE SFP ports (or 2*10GE SFP+ ports), 4*10GE SFP+ vrata, 2*12GE stack ports, dual built-in AC power)
CloudEngine S5735S24T8J4XEZ-V2 CloudEngine S5735-S24T8J4XEZ-V2 (24*10/100/1000vrata BASE-T, 8*2.5GE SFP ports (or 2*10GE SFP+ ports), 4*10GE SFP+ vrata, 2*12GE stack ports, expansion card slot, brez napajalnega modula)
CloudEngine S5735S24P8J4XEZ-V2 CloudEngine S5735-S24P8J4XEZ-V2 (24*10/100/1000vrata BASE-T (PoE+), 8*2.5GE SFP ports (or 2*10GE SFP+ ports), 4*10GE SFP+ vrata, 2*12GE stack ports, expansion card slot, brez napajalnega modula)
CloudEngine S5735S48T4XE-V2 CloudEngine S5735-S48T4XE (48 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports, brez napajalnega modula)
CloudEngine S5735S48T4XE-XA-V2 CloudEngine S5735-S48T4XE-XA-V2 (48*10/100/1000vrata BASE-T, 4*10GE SFP+ vrata, 2*12GE stack ports, dual built-in AC power)
CloudEngine S5735S48T4XEZ-V2 CloudEngine S5735-S48T4XEZ-V2 (48*10/100/1000vrata BASE-T, 4*10GE SFP+ vrata, 2*12GE stack ports, expansion card slot, brez napajalnega modula)
CloudEngine S5735S48P4XE-V2 CloudEngine S5735-S48P4XE-V2 (48 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GE stack ports, PoE+, brez napajalnega modula)
CloudEngine S5735S48P4XEZ-V2 CloudEngine S5735-S48P4XEZ-V2 (48*10/100/1000vrata BASE-T (PoE+), 4*10GE SFP+ vrata, 2*12GE stack ports, expansion card slot, brez napajalnega modula)
CloudEngine S5735S48U4XE-V2 CloudEngine S5735-S48U4XE-V2 (48 x 10/100/1000Base-T vrata, 4 x 10 GE SFP+ vrata, 2 x 12GEstack ports, PoE++, brez napajalnega modula)
PAC80S12-CN 80 W AC napajalni modul
PAC180S12-CN 180 W AC napajalni modul
PDC240S12-CN 240 W enosmerni napajalni modul
PAC600S12-PB 600W AC &240 V DC napajalni modul
PDC1K2S12-CE 1200 W enosmerni napajalni modul
PAC600S56-EB 600 W AC PoE napajalni modul
PAC1000S56-EB 1000 W AC PoE napajalni modul
PDC1000S56-EB 1000 W DC PoE napajalni modul
N1-S57S-M-Lic Osnovni SW serije S57XX-S,Na napravo
N1-S57S-M-SnS1Y Osnovni SW serije S57XX-S,SnS,Na napravo,1leto
N1-S57S-F-Lic N1-CloudCampus,Fundacija,Serija S57XX-S,Na napravo
N1-S57S-F-SnS1Y N1-CloudCampus,Fundacija,Serija S57XX-S,SnS,Na napravo,1leto
N1-S57S-A-Lic N1-CloudCampus,Napredno,Serija S57XX-S,Na napravo
N1-S57S-A-SnS1Y N1-CloudCampus,Napredno,Serija S57XX-S,SnS,Na napravo,1leto
N1-S57S-FToA-Lic N1-Nadgradnja-Osnova na Napredno,S57XX-S,Na napravo
N1-S57S-FToA-SnS1Y N1-Nadgradnja-Osnova na Napredno,S57XX-S,SnS,Na napravo,1leto

Huawei S5735-S24T4XEZ-V2 Switch Product Applications

S5735-S24T4XEZ-V2 application
