Huawei S5720S-28TP-PWR-LI-ACL Switch
- Opis
- Povpraševanje
- Priponka
Opis
Huawei S5720S-28TP-PWR-LI-ACL Switch is simplified Gigabit Ethernet switch with 8 Ethernet 10/100/1000 PoE+ ports, 16 Ethernet 10/100/1000Base-T ports, 2 Gig SFP vrata, 2 of which are dual-purpose 10/100/1000Base-T or SFP ports AC power supply PoE+ Forwarding performance: 46.5Mpps and Switching Capacity: 336Gbit/s
Huawei S5720S-28TP-PWR-LI-ACL Switch Product Overview
Huawei S5720S-28TP-PWR-LI-ACL Switch is simplified Gigabit Ethernet switch with 8 Ethernet 10/100/1000 PoE+ ports, 16 Ethernet 10/100/1000Base-T ports, 2 Gig SFP vrata, 2 of which are dual-purpose 10/100/1000Base-T or SFP ports AC power supply PoE+ Forwarding performance: 46.5Mpps and Switching Capacity: 336Gbit/s. it supports strict ARP learning. This feature prevents ARP spoofing attackers from exhausting ARP entries so that users can connect to the Internet normally.Building on next-generation, high-performance hardware and Huawei Versatile Routing Platform (VRP), Huawei S5720S-28TP-PWR-LI-ACL supports intelligent stack (iStack), flexible Ethernet networking, and diversified security control. Poleg tega, it provides customers with an energy-saving, easy-to-manage, easy-to-expand, and cost-effective gigabit to the desktop solution. Dodatno, Huawei S5720S-28TP-PWR-LI-ACL provides telemetry technology to collect device data in real time and send the data to Huawei campus network analyzer CampusInsight, and supports a variety of intelligent O&M features for audio and video services, including the enhanced Media Delivery Index (eMDI).
Huawei S5720S-28TP-PWR-LI-ACL Switch Product Pictures
Huawei S5720S-28TP-PWR-LI-ACL Switch Product Specifications
| Postavka | Opis |
| Znamka | Huawei |
| Model | S5720S-28TP-PWR-LI-ACL |
| Številka dela | 98010635 |
| Spomin (Oven) | 512 MB |
| Flash | 512 MB skupaj. Za ogled razpoložljive velikosti bliskovnega pomnilnika, zaženite ukaz za prikaz različice. |
| Povprečni čas med napakami (MTBF) | 42 leta |
| Povprečni čas za popravilo (MTTR) | 2 ure |
| Razpoložljivost | > 0.99999 |
| Prenapetostna zaščita servisnih vrat | Skupni način: ±7 kV |
| Prenapetostna zaščita napajalnika | ±6 kV v diferenčnem načinu, ±6 kV v skupnem načinu |
| Utež (z embalažo) | 4.5 kg (9.92 lb) |
| Stack vrata | Twenty-four 10/100/1000BASE-T ports and two 1000BASE-X ports |
| RTC | Ne podpira |
| RPS | Ne podpira |
| PoE | Podprto |
| Območje nazivne napetosti | 100 V AC do 240 V AC, 50/60 Hz |
| Največje napetostno območje | 90 V AC do 264 V AC, 47 Hz do 63 Hz |
| Največja poraba energije (100% prepustnost) | Ne zagotavlja funkcije PoE: 24.4 W |
| 100% PoE obremenitve: 165.6 W (system power consumption: 42.4 W, PoE: 123.2 W) | |
| Delovna temperatura | 0°C do 45 °C (32°F do 113 °F) na nadmorski višini 0-1800 m (0-5906 ft.) |
| Temperatura skladiščenja | -40°C do +70 °C (-40°F do +158 °F) |
| Hrup pri normalni temperaturi (27°C, zvočna moč) | Noise-free (no fans) |
| Relativna vlažnost | 5% do 95%, nekondenzacijski |
| Delovna višina | 0-5000 m (0-16404 ft.) |
| Certificiranje | EMC certifikat |
| Varnostno potrdilo | |
| Certificiranje proizvodnje | |
| Tipična poraba energije (30% of traffic load) Tested according to ATIS standard EEE enabled No PoE power consumption |
19.4 W |
| Dimenzije (V x Š x G) | Osnovne dimenzije (razen delov, ki štrlijo iz telesa): 43.6 mm x 442.0 mm x 224.8 mm (1.72 v. x 17.4 v. x 8.85 v.) |
| Največje dimenzije (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 233.8 mm (1.72 v. x 17.4 v. x 9.21 v.) |
Huawei S5720S-28TP-PWR-LI-ACL Switch Product Features
- Huawei S5720S-28TP-PWR-LI-ACL Switch supports intelligent stack (iStack). This technology combines multiple switches into a logical switch. Članska stikala v skladu izvajajo varnostno kopiranje redundance za izboljšanje zanesljivosti naprave in uporabljajo združevanje povezav med napravami za izboljšanje zanesljivosti povezave.
- Huawei S5720S-28TP-PWR-LI-ACL Switch supports the sFlow function. Uporablja metodo, definirano v standardu sFlow, za vzorčenje prometa, ki poteka skozenj, in pošiljanje vzorčenega prometa v zbiralnik v realnem času. Zbrana statistika prometa se uporablja za izdelavo statističnih poročil, pomaga podjetjem vzdrževati njihova omrežja
- Huawei S5720S-28TP-PWR-LI-ACL Switch supports intelligent stack (iStack). This technology combines multiple switches into a logical switch. Članska stikala v skladu izvajajo varnostno kopiranje redundance za izboljšanje zanesljivosti naprave in uporabljajo združevanje povezav med napravami za izboljšanje zanesljivosti povezave.
