Opis

Huawei CE6855-48XS8CQ Switch is a data center switch with Downlink Ports 48×10 GE SFP+ and Uplink Ports 8×40/100 GE QSFP28

Huawei CE6855-48XS8CQ Switch Product Overview

Huawei CE6855-48XS8CQ Switch is a next-generation 10G Ethernet switch designed for data centers and high-end campus networks. The product provides high-performance, high-density 10GE ports, and low latency. The CE6800 hardware has an advanced architectural design with 40GE uplink ports and the industry’s highest density of 10GE access ports. By using Huawei VRP8 software platform, CE6855-48XS8CQ offers extensive data center service features and high stacking capability. Poleg tega, the airflow direction (front-to-back or back-to-front) can be changed. CE6800 switches can work with CE12800 switches to build an elastic, virtualized, high-quality fabric that meets the requirements of cloud-computing data centers. Poleg tega, CE6800 switches provide high-density 10GE access to help enterprises and carriers build a scalable data center network platform in the cloud computing era. Uporabljajo se lahko tudi kot združevalna ali jedrna stikala za podjetniška kampusna omrežja.

Huawei CE6855-48XS8CQ Switch Product Pictures

CE6855-48XS8CQ price and specs ycictCE6855-48XS8CQ specs ycict

CE6855-48XS8CQ price and specs ycictS5735-S24T4XE-V2 price ycict

Huawei CE6855-48XS8CQ Switch Product Specifications

Znamka Huawei
Parametri CloudEngine 6855-48XS8CQ
Vrata za povezavo navzdol 48 x 10 GE SFP+
Vrata za navzgornjo povezavo 8 x 40/100 GE QSFP28
Preklopna zmogljivost 2.56 Tbit/s
Posredovanje uspešnosti 1200 mpps
O&M Telemetrija
Netstream
ERSPAN+
IFIT
Packet Event
Funkcije podatkovnega centra 1588v2
MACsec
Usmerjanje in premoščanje VXLAN
BGP-EVPN
M-LAG
PFC、AI ECN
Največja poraba energije 298 W
Napajanje 600W AC&240V DC
1200W DC
Delovna napetost AC:90V to 290V;HVDC: 190V~290V
DC: -48V:-38.4V do -72V; +48V DC:+40V DC to +57V DC
Zanesljivost LACP
BFD za BGP, JE-JE, OSPF, static route, and VXLAN
BFD na osnovi strojne opreme
DPFR
MoFRR

Huawei CE6855-48XS8CQ Switch Product Features

  • CE6800 provides the industry’s highest performance in a 1 U TOR. The switch provides forwarding performance of 1,080 Mpps and supports L2/L3 line-speed forwarding.
  • CE6800 supports Super Virtual Fabric (SVF), which can virtualize multiple homogeneous or heterogeneous physical switches into one logical switch to simplify network management and improve reliability.
  • CE6800 series switches have energy-saving chips and can measure system power consumption in real time. Fan speed can be adjusted dynamically based on system consumption. These energy saving technologies reduce O&M costs and contribute to a greener data center.
  • CE6800 supports the IETF Transparent Interconnection of Lots of Links (TRILČ) protocol and can be used on a large Layer 2 TRILL network with GE/10GE servers. Omrežje TRILL lahko vsebuje več kot 500 vozlišča, omogočanje prilagodljive uvedbe storitev in virtualnega stroja velikega obsega (VM) migracije.

Huawei CE6855-48XS8CQ Switch Product Ordering Info

CE6850-HI-B00 CE6850-48S6Q-HI Switch (2*600W AC napajalni modul, 2*VENTILATORSKA škatla, Port Side Exhaust)
CE6850-EI-B00 CE6850-48S4Q-EI Switch (2*350W AC napajalni modul, 2*VENTILATORSKA škatla, Port side exhaust)
CE6850-EI-B01 CE6850-48T4Q-EI Switch (2*600W AC napajalni modul, 2*VENTILATORSKA škatla, Port side exhaust)
CE6810-EI-B00 CE6810-48S4Q-EI Switch (2*600W AC napajalni modul, 2*VENTILATORSKA škatla, Port side exhaust)
CE6810-LI-B00 CE6810-48S4Q-LI Switch (2*600W AC napajalni modul, 2*VENTILATORSKA škatla, Port side exhaust)
CE6810-LI-B01 CE6810-48S-LI Switch (2*600W AC napajalni modul, 2*VENTILATORSKA škatla, Port side exhaust)
CE6810-LI-B10 CE6810-LI Bundle 10 (CE6810-48S4Q-LI mainframe, 4*QSFP-40G-iSR4, Without Fan and Power Module)
CE6810-LI-B11 CE6810-LI Bundle 11 (CE6810-48S-LI mainframe, 2*QSFP-40G-iSR4, 8*SFP-10G-USR, Without Fan and Power Module)
CE6850U-48S6Q-HI CE6850U-48S6Q-HI Switch (48-Port 10GE SFP+, support 2/4/8G FC, 6-Port 40GE QSFP+, Without Fan and Power Module)
CE6850U-24S2Q-HI CE6850U-24S2Q-HI Switch (24-Port 10GE SFP+, support 2/4/8G FC, 2-Port 40GEQSFP+, Without Fan and Power Module)
CE6851-48S6Q-HI CE6851-48S6Q-HI Switch (48-Port 10GE SFP+, 6-Port 40GE QSFP+, Without Fan and Power Module)
CE6850-48T6Q-HI CE6850-48T 6Q-HI Switch (48-Port 10GE RJ45, 6-Port 40GE QSFP+, Without Fan and Power Module)
CE6850-48S6Q-HI CE6850-48S6Q-HI Switch (48-Port 10GE SFP+, 6-Port 40GE QSFP+, Without Fan and Power Module)
CE6850-48S4Q-EI CE6850-48S4Q-EI Switch (48-Port 10GE SFP+, 4-Port 40G QSFP+, Without Fan and Power Module)
CE6850-48T4Q-EI CE6850-48T4Q-EI Switch (48-port 10GE RJ45, 4-port 40G QSFP+, Without Fan and Power Module)
CE6810-48S4Q-EI CE6810-48S4Q-EI Switch (48-Port 10GE SFP+, 4-Port 40G QSFP+, Without Fan and Power Module)
CE6810-48S4Q-LI CE6810-48S4Q-LI Switch (48-Port 10GE SFP+, 4-Port 40G QSFP+, Without Fan and Power Module)
CE6810- CE6810-32T16S4Q-LI Switch (32-port 10GE RJ45, 16-Port 10GE SFP+, 4-Port 40G
32T16S4Q-LI QSFP+, Without Fan and Power Module)
CE6810-48S-LI CE6810-48S-LI Switch (48-Port 10GE SFP+, Without Fan and Power Module)
CE6810-24S2Q-LI CE6810-24S2Q-LI Switch (24-Port 10GE SFP+, 2-Port 40G QSFP+, Without Fan and Power Module)
VENTILATOR-060A-F Fan box (F, Stranski dovod plošče FAN )
VENTILATOR-060A-B Fan box (B, Stranski izpuh na plošči FAN)
FAN-40EA-F Fan box (EA, Spredaj nazaj, Stranski dovod plošče FAN)
FAN-40EA-B Fan box (EA, Zadaj spredaj, Stranski izpuh na plošči FAN)
PAC-600WB-F 600W AC&240V DC napajalni modul (Stranski dovod električne plošče)
PAC-600WB-B 600W AC&240V DC napajalni modul (Stranski izpuh električne plošče)
PHD-600WA-F 600W HVDC napajalni modul (Stranski dovod električne plošče)
PHD-600WA-B 600W HVDC napajalni modul (Stranski izpuh električne plošče)
PAC-350WA-F 350W AC napajalni modul (Spredaj nazaj, Stranski dovod električne plošče)
PAC-350WA-B 350W AC napajalni modul (Zadaj spredaj, Stranski izpuh električne plošče)
PAC-600WA-F 600W AC napajalni modul (Spredaj nazaj, Stranski dovod električne plošče)
PAC-600WA-B 600W AC napajalni modul (Zadaj spredaj, Stranski izpuh električne plošče)
PDC-350WA-F 350W DC Power Module (Spredaj nazaj, Stranski dovod električne plošče)
PDC-350WA-B 350W DC Power Module (Zadaj spredaj, Stranski izpuh električne plošče)
CE68-LIC-VXLAN CloudEngine 6800 VXLAN Function
CE68-LIC-FCF16 CloudEngine 6800 FCF 16 Pristanišča
CE68-LIC-FCFAL CloudEngine 6800 FCF Vsa vrata
CE6800-LIC-NPV CloudEngine 6800 FCOE NPV Function

Huawei CE6855-48XS8CQ Switch Product Applications
