Huawei SSN1BPA Board is Optical Booster & Pre-amplifier Board (-38dBm~-10dBm,22dB;-6dBm~+3dBm,17dBm, LC)

Huawei SSN1BPA Board Product Overview

Huawei SSN1BPA Board consists of 1 power amplifier and 1 preamplifier board. When the optical signal is transmitted over a long distance, the signal attenuation is more. In order for the optical receiver to receive the normal optical signal, it is necessary to add an optical power amplifier board (BA) and a pre-amplifier board (PA).

Huawei N1BPA consists of 2 EDFA optical modules, and N2BPA consists of 1 EDFA optical module, which is used to generate optical amplification effects. The BPA board is an optical power amplifier and preamplifier board. It provides 1 channel power amplifier (BA) a 1 channel preamplifier (PA), which are respectively applied to the sending end and receiving end of OptiX OSN equipment.

Huawei SSN1BPA Board Product Pictures

Huawei SSN1BPA Board YCICT Huawei SSN1BPA Board PRICE AND SPECSHuawei SSN1BPA Board YCICT NEW AND ORIGINAL Huawei SSN1BPA Board PRICE AND SPECS

Huawei SSN 1BPA Board YCICT Huawei SSN1BPA Board PRICE AND SPECS NEW AND ORIGINALHuawei SSN1BPA Board YCICT Huawei SSN1BPA Board PRICE AND SPECS NEW

Huawei SSN1BPA Board Product Specifications

Položka Index
Input wavelength range (nm) BA:1530~1565
PA:1550.12
Input optical power range (dBm) BA–6~+3
PA
N1BPA–38~–10
N2BPA–44~–10
Output optical power range (dBm) N1BPA:+14~+14.5或+17~+17.5(BA)
N1BPA–22~+15(PA)
N2BPA:+14~+14.5(BA)
N2BPA–22~+23(PA)
Noise figure (dB) BA:<6.5
PA:<6
Minimum signal gain (dB) 22
When BPA preamplification is used for loopback, pay attention to the range of input optical power to avoid damage to the optical module.
Laser safety level
The laser safety level of the single board is CLASS 1M, and the maximum output optical power of the single board optical port is between 10dBm (10mW) and 22.15dBm (164mW).
Mechanical index
The mechanical indicators of BPA boards are as follows:
Veľkosť dosky: 25.4mm (šírka) × 235.2mm (hĺbka) × 261.4mm (výška)
N1BPA weight: 1.0kg
N2BPA weight: 1.2kg
Spotreba energie
The maximum power consumption of the N1BPA board at normal temperature (25 °C) is 20W.
The maximum power consumption of the N2BPA board at normal temperature (25 °C) is 11W.

Huawei SSN1BPA Board Product Features

  • Basic Function
    Increase the transmission optical power of the circuit board to + 13dBm ~ + 15dBm or + 15dBm ~ + 17dBm, so that the transmission distance can reach 120km or 130km or more (G.652 fiber, loss is calculated as 0.275dB / km).
  • Pre-amplification function
    Provide PA module to complete the pre-amplification of the received optical signal, which can make the small signal power gain 22dB ~ 25dB (N1BPA), 22dB ~ 33dB (N2BPA).
  • Support EDFA
    Support EDFA (Erbium-Doped Fiber Amplifier) module laser temperature automatic control and optical power automatic control.
    Support EDFA module input and output optical power automatic monitoring and optical power query.
    Support the protection function of EDFA module. When there is no input light, the laser is automatically turned off. When the input light is restored, the laser is automatically turned on.
    Performance monitoring and alarm monitoring
    Support the reporting of laser performance parameters. Provide abundant alarms and performance events to facilitate equipment management and maintenance.
  • software upgrade
    Support the smooth upgrade and expansion of software.

Huawei SSN1BPA Board Product Ordering Info

SSN1BA2(14,LC) Optical booster amplifier board (-6dBm ~ + 3dBm, 14dBm, LC)
SSN1BA2(17,LC) Optical booster amplifier board (-6dBm ~ + 3dBm, 17dBm, LC)
SSN1BPA(17/-38,LC) Optical booster and pre-amplifier board (-38dBm ~ -10dBm, 22dB; -6dBm ~ + 3dBm, 17dBm, LC)
SSN2BPA(14/-38,LC) Optical booster and pre-amplifier board (-38dBm~-10dBm,22dB~33dB;-6dBm~+3dBm,14dBm,LC)

Huawei SSN1BPA Board Product Applications
