Name: Huawei S5700-52X-LI-48CS-AC Switch
SKU: Huawei S5700-52X-LI-48CS-AC Switch
Price: 636.28 USD
Availability: InStock

Huawei S5700-52X-LI-48CS-AC Switch

SKU: Huawei S5700-52X-LI-48CS-AC Switch Categorie: INTRERUPATOR Etichete: Huawei, Intrerupator

Descriere
Anchetă
Atașament

Descriere

Huawei S5700-52X-LI-48CS-AC Switch is a simplified Gigabit Ethernet Switch with 48*GE CSFP ports or 24 *Porturi GE SFP, 4* Combo 10/100/1,000 Porturi Ethernet Base-T, 4*10 GE SFP+ ports AC Power.

Huawei S5700-52X-LI-48CS-AC Switch Product Overview

Huawei S5700-52X-LI-48CS-AC Switch is a simplified Gigabit Ethernet Switch with 48*GE CSFP ports or 24 *Porturi GE SFP, 4* Combo 10/100/1,000 Porturi Ethernet Base-T, 4*10 GE SFP+ ports AC Power. The switch is a next-generation energy-saving gigabit Layer 2 Ethernet switch offering flexible GE access ports and extensive services. în plus, it provides improved PoE solutions. It can use PoE power supplies with different power levels to provide -48 V DC power for powered devices (PDs), such as IP Phones, WLAN APs, and Bluetooth APs. As a power sourcing equipment (PSE), the S5700-LI PWR complies with IEEE 802.3af and 802.3at (PoE+) and can work with PDs that are incompatible with 802.3af or 802.3at. Each port provides a maximum of 30 W of power, complying with IEEE 802.3at. The PoE+ function increases the maximum power available on each port and implements intelligent power management for high-power consumption applications. This facilitates the ease of PD use. PoE ports continue to work while in power-saving mode. Users can configure whether and when a PoE port supplies power. Prin urmare, Huawei S5700-52X-LI-48CS-AC Switch offers customers with a green, easy-to manage, easy-to-expand, and cost-effective gigabit to the desktop solution.

Huawei S5700-52X-LI-48CS-AC Switch Product Pictures

Huawei S5700-28P-LI-DC huawei 5700 Huawei S5700-52X-LI-48CS-AC Switch price and specs ycict

Huawei S5735-L48T4S-A1 Switch

Huawei S5700-52X-LI-48CS-AC Switch Product Specifications

Articol	Descriere
Marca	Huawei
Model	S5700-52X-LI-48CS-AC
Numărul piesei	2357823
Port	48GE CSFP ports or 24 Porturi GE SFP, 4* Combo 10/100/1,000 Porturi Ethernet Base-T, 4*10 GE SFP+ ports AC Power
Memorie (RAM)	256 MB
Flash	200 MB
Timpul mediu dintre eșecuri (MTBF)	92.57 ani
Timp mediu pentru reparații (MTTR)	2 ore
Disponibilitate	> 0.99999
Protecție la supratensiune în portul de service	Combo electrical port: ±2 kV in common mode
Protecție la supratensiune a sursei de alimentare	±6 kV în regim diferenţial, ±6 kV în modul comun
Dimensiuni (Înălțime x L x A)	43.6 mm x 442.0 mm x 220.0 mm (1.72 în. X 17.4 în. X 8.7 în.)
Greutate (cu ambalaj)	3.4 kg (7.5 livre)
Stiva porturi	Four uplink 10GE SFP+ ports
RTC	Sprijinit
RPS	Sprijinit
PoE	Nu sunt acceptate
Gama de tensiune nominală	100 V AC la 240 V AC, 50/60 Hz
Domeniul maxim de tensiune	90 V AC la 264 V AC, 47 Hz la 63 Hz
Consum maxim de energie (100% debitului, viteza maximă a ventilatoarelor)	79.93 W
Temperatura de Operare	0°C până la 45°C (32°F până la 113 °F) la o altitudine de 0-1800 m (0-5906 ft.)
Temperatura de depozitare	-40°C până la +70°C (-40°F până la +158 °F)
Zgomot la temperaturi normale (27°C, puterea sonoră)	< 67.3 dB(A)
Umiditate relativă	5% la 95%, necondensabil
Altitudine de operare	0-5000 m (0-16404 ft.)
Certificare	Certificare EMC Certificare de siguranță Certificare de fabricație
Consumul de energie tipic (30% a încărcăturii de trafic) Tested according to ATIS standard EEE enabled No PoE power consumption	69.17 W

Huawei S5700-52X-LI-48CS-AC Switch Product Features

Supporting enhanced Ethernet reliability technologies, such as Smart Link and RRPP (Rapid Ring Protection Protocol), which implement millisecond-level protection switchover and ensure network reliability. The S5700 also provides Smart Link multi-instance and RRPP multi-instance to implement load balancing among links, optimizing bandwidth usage.

Supporting the Smart Ethernet Protection (SEP) protocol, a ring network protocol applied to the link layer on an Ethernet network. SEP can be used on open ring networks and can be deployed on upper layer aggregation devices to provide fast switchover (within 50 Domnișoară), ensuring continuous transmission of services. SEP features simplicity, fiabilitate ridicată, fast switchover, easy maintenance, and flexible topology, facilitating network planning and management.
Providing improved PoE solutions. It can use PoE power supplies with different power levels to provide -48 V DC power for powered devices (PDs), such as IP Phones, WLAN APs, and Bluetooth APs. As a power sourcing equipment (PSE), the S5700-LI PWR complies with IEEE 802.3af and 802.3at (PoE+) and can work with PDs that are incompatible with 802.3af or 802.3at. Each port provides a maximum of 30 W of power, complying with IEEE 802.3at. The PoE+ function increases the maximum power available on each port and implements intelligent power management for high-power consumption applications. This facilitates the ease of PD use. PoE ports continue to work while in power-saving mode. Users can configure whether and when a PoE port supplies power.

Supporting automatic configuration, plug-and-play features, and batch remote upgrades. These capabilities simplify device management and maintenance and reduce maintenance costs. The S5700 supports SNMP v1/v2/v3 and provides flexible methods for managing devices. Users can manage the S5700 using the CLI amd Web NMS. The NQA function assists users with network planning and upgrades. în plus, the S5700 supports NTP, SSH v2, HWTACACS, RMON, log hosts, and port-based traffic statistics
