ZTE SCXM Control Card

Description

ZTE SCXM Control Card is Switching and Control Board for ZXA10 C300/C350 OLT supporting 480 Gbps switching capacity and 32k MAC address table

ZTE SCXM Control Card Product Overview

ZTE SCXM Control Card is to control and manage the system for all service cards in ZXA10 C300. Additionally, ZXA10 C300 supports the following switching and control cards

SCXL: supports 800 Gbps switching capacity and 32 K MAC address table.

SCXM: supports 480 Gbps switching capacity and 32 K MAC address table.

SCXN: supports 480 Gbps switching capacity, 64 K MAC address table, and VoIP function (with VoIP daughter-card)。

ZTE ZXA10 C300 OLT is the world’s first future-proof and largest capability optical access platform, is developed with mass optical access roll-out as well as the economy in mind. Its powerful functions and high performance.

ZTE SCXM Control Card Product Pictures

ZTE SCXM Control Card Product Specifications

Control and switching cards	SCTM – Suitable for XGPON1, supports 16 port GPON cards, higher switching power, 4x 10GE uplink interface, 2x management interface
	SCXN – Supports 16 port GPON cards, 4x GE uplink interface, 2x management interface
	SCXM– supports 480 Gbps switching capacity and 32 K MAC address table.
	SCXL – No uplink interfaces, 2x management interface
GPON cards	GTXO – 4/8 XGPON1 ports, split ratio up to 1:256
	GTGO – 8 GPON ports, split ratio up to 1:256
	GTGH – 16 GPON ports, split ratio up to 1:128
	FTGK – 48 P2P ports (WDM) or 24 GE ports (separated fibres for uplink/downlink)
Uplink cards	GUFQ – 4x SFP (GE)
	GUSQ – 2x SFP (GE), 2x RJ45 (GE)
	XUTQ – 4x SFP (10GE)
	HUTQ – 4x SFP (2x10GE, 2xGE)
	HUVQ – 4x SFP (2x10GE/GE, 2xGE/FE)

ZTE SCXM Control Card Product Features

Chassis Configuration (21”)

Total 23 slots

16 slots for universal line cards

2 slots for switch & control cards

2 slots for power cards

2 slots for uplink and cascading interfaces

1 slot for environment detecting card

Chassis Configuration  (19”)

Total 21 slots

14 slots for universal line cards

2 slots for switch& control cards

2 slots for power cards

2 slots for uplink and cascading interfaces

1 slot for environment detecting card

Subscriber Card Density

GPON card: 8/16 ports per card

P2P card: 24/48  ports per card

XG PON1 card: 8  ports per card

Uplink interface card

4*10GE uplink per card

2*10GE+2*GE uplink per card

4*GE uplink per card

1*STM-4/OC12 or 2*STM-1/OC3 TDM uplink per card

32* E1/T1 uplink card ( balanced and unbalanced)

Environment detecting card

2 * Hz/Bit external clock interfaces

5 * Environment detecting interfaces
