Description
ZTE ETTO Service Board is 8 ports 10G EPON board with 8 10G EPON modules for C320 C300 OLT Equipment
ZTE ETTO Service Board Product Overview
ZTE ETTO Service Board is an 8-port 10G EPON OLT interface board, which cooperates with ONU to realize EPON access service.
ZXA10 C320 is new-generation compact OLT, only 2U high, saving installation space; high line card density: industry-leading 16-port GPON/EPON and 48-channel P2P board capability, single-frame can provide 32 G/EPON ports and 96 channels P2P GE port; ZTE C320 supports GPON/EPON/P2P/10G EPON/XG-PON1 with the same platform access, and will also support TWDM-PON technology; unified bearer voice, high-speed Internet access, IPTV, traditional TDM and mobile backhaul services. Integrated access; adopts large-scale OLT hardware and software architecture, supports architecture evolution, is compatible with ZXA10 C300 service boards, and saves board costs.
ZTE ETTO Service Board Product Pictures
ZTE ETTO Service Board Product Specifications
| Brand | ZTE |
| Specification | ETTO |
| Port quantity | 8 |
| MAX Split ratio | 1: 128 |
| Forwarding Rate | 80Gbit/s |
| Rate model | Symmetric Rate model |
| Asymmetric Rate Model | |
| Maximum Number of LLID | 256 |
| Maximum Number of Service Flows Supported by the Board | 16368 |
| Maximum frame length | 2052 bytes |
| Maximum Number of MAC | 16384 |
| Maximum differential fibre distance (km) | 40 |
| Board supporting downstream FEC | Yes |
| Board supporting upstream FEC | Yes |
| CAR | Yes |
| Temperature query and high temperature alarm | Yes |
| Automatic power shutdown in case of a high temperature | Yes |
| Rogue ONT detection | Yes |
| 1588v2 | EPON model:Yes |
| 10G EPON model:No | |
| High temperature automatic concern | Yes |
| Rogue ONT Detection and Isolation Support | Yes |
| Working temperature | -40℃~+65℃ |
| Maximum Power waste | 65w |
| Dimensions (W x D x H) | 490 mm x 325mm x 75mm |
ZTE ETTO Service Board Product Features
- High Density, energy Saving, low power consumption, support 1024 access users
- Manual shutdown of idle PON port to avoid power waste
- Supporting the maximum distance difference between two ONUs and PON ports under the same PON port 40 km, simplified network planning
- Intelligent Management Channel
- Level 4 HQoS to Improve User Experience
- 9216 Jumbo frame, greatly improving transmission efficiency
- Easy to operate and maintain
- Real-time hooligans ONU detection and isolation to ensure stable operation of business
- Variable Length OMCI to Improve Upgrade Efficiency and Shorten Business Interruption Time
- 1:128 eOTDR, Accurate Fault Responsibility Division and Fast Fault Location
- 8 10G EPON Port (XFP Optical Module):
- Maximum spectral ratio:1:128
ZTE ETTO Service Board Product and More service Boards
| GTGO | 8 ports GPON board with 8 B+ modules. |
| GTGO | 8 ports GPON board with 8 C+ modules. |
| GTGO | 8 ports GPON board with 8 C++ modules. |
| GTGH | 16 ports GPON board with 16 B+ modules. |
| GTGH | 16 ports GPON board with 16 C+ modules. |
| GTGH | 16 ports GPON board with 16 C++ modules. |
| GTTO | 8 ports 10G GPON board with 8 10G GPON modules |
| GTXO | 8 ports 10G GPON board with 8 10G GPON modules |
| ETGO | 8 ports EPON board with 8 modules. |
| ETGH | 16 ports EPON board with 16 modules |
| ETTO | 8 ports 10G EPON board with 8 10G EPON modules |
ZTE ETTO Service Board Product Applications
