Description
Huawei S5731-L4T2S-RUA Switch is all-gigabit Ethernet switch based on the innovative architecture with 4 x 10/100/1000Base-T ports, 1 x GE SFP port, 1 x GE port and an SC connector
Huawei S5731-L4T2S-RUA Switch Product Overview
Huawei S5731-L4T2S-RUA Switch is all-gigabit Ethernet switch based on the innovative architecture, offering all-gigabit data access capabilities. Based on the simplified architecture, the switch can function as a remote unit and works with the central switch to implement simplified network deployment. The remote units are connected to the central switch through optical cables or optical-electrical hybrid cables, which does not require planning, configuration, management, and plug-and-play. When a device is expanded or faulty, replace the device with a new one, simplifying network planning, deployment, and routine O&M. Considering them, S5731-L4T2S-RUA can be widely used in enterprise offices, education, hotels, and healthcare, helping enterprises build green and low-carbon buildings.
Huawei S5731-L4T2S-RUA Switch Product Pictures
Huawei S5731-L4T2S-RUA Switch Product Specifications
| Product Model | CloudEngine S5731-L4P2HW-RUA | CloudEngine S5731-L4P2HT-RUA | CloudEngine S5731-L4T2S-RUA | CloudEngine S5731-L4P2S-RUA | CloudEngine S5731-L4T2ST-RUA | CloudEngine S5731-L4P2ST-RUA |
| Forwarding Performance | 9 Mpps | 9 Mpps | 9 Mpps | 9 Mpps | 9 Mpps | 9 Mpps |
| Switching Capacity2 | 12 Gbit/s | 12 Gbit/s | 12 Gbit/s | 12 Gbit/s | 12 Gbit/s | 12 Gbit/s |
| Uplink Ports | 1 x GE SFP (hybrid), 1 x GE SFP (hybrid) | 1 x GE SFP (hybrid), 1 x 10/100/1000 Base-T Ethernet port | 1 x GE SFP (built-in SC optical module), 1 x GE SFP | 1 x GE SFP (built-in SC optical module), 1 x GE SFP | 1 GE SFP, 1 x 10/100/1000 Base-T Ethernet ports | 1 GE SFP, 1 x 10/100/1000 Base-T Ethernet ports |
| Downlink Ports | 4 x 10/100/1000 Base-T Ethernet ports | 4 x 10/100/1000 Base-T Ethernet ports | 4 x 10/100/1000 Base-T Ethernet ports | 4 x 10/100/1000 Base-T Ethernet ports | 4 x 10/100/1000 Base-T Ethernet ports | 4 x 10/100/1000 Base-T Ethernet ports |
| Power Supply Type | AC/DC adapter or optical-electrical PoE | AC/DC adapter, PoE or optical-electrical PoE | AC/DC adapter | AC/DC adapter | AC/DC adapter | AC/DC adapter |
| PoE++ | PoE++ | PoE++ | N/A | PoE++ | N/A | PoE++ |
Huawei S5731-L4T2S-RUA Switch Product Features
- The remote units provide the full line-speed forwarding capability. All ports support non-blocking data packet forwarding, providing users with high-speed access experience and meeting the requirements of high-bandwidth services such as HD video conferencing, online video, and large file download.
- Flexible installation: Supports flexible installation modes, such as wall embedding, DIN-rail-mounted, wall-mounted, and desktop-mounted, meeting all-scenario installation requirements.
- The remote units of PoE module support PoE++ and provides data access and power supply for terminals such as Wi-Fi 6 APs, IP cameras, and IP phones. Some remote modules can provide power supply based on optical-electrical hybrid cable. In this way, the power supply is centralized and the network is disconnected from the power supply.
Huawei S5731-L4T2S-RUA Switch and More Models
CloudEngine S5731-L8T2ST-RUA 8x 10/100/1000Base-T ports, 1 x GE SFP port, 1*10/100/1000BASE-T port
Huawei S5731-L4T2S-RUA Switch Ordering Info
| CloudEngine S5731-L4P2HW-RUA | CloudEngine S5731-L4P2HW-RUA (4*10/100/1000BASE-T ports, PoE++, 2*GE hybrid optical- electrical SFP ports, AC power, power adapter) |
| CloudEngine S5731- L4T2S-RUA | CloudEngine S5731-L4T2S-RUA (4*10/100/1000BASE-T ports, 1*GE SFP port, 1*GE port with an SC connector, TX1310 nm/RX1490 nm, AC power, power adapter) |
| CloudEngine S5731- L4P2S-RUA | CloudEngine S5731-L4P2S-RUA (4*10/100/1000BASE-T ports, PoE++, 1*GE SFP port, 1*GE port with an SC connector, TX1310 nm/RX1490 nm, AC power, power adapter) |
| CloudEngine S5731- L4T2ST-RUA | CloudEngine S5731-L4T2ST-RUA (4*10/100/1000BASE-T ports, 1*GE SFP port, 1*10/100/1000BASE-T port, AC power, power adapter) |
| CloudEngine S5731- L4P2ST-RUA | CloudEngine S5731-L4P2ST-RUA (4*10/100/1000BASE-T ports, PoE++, 1*GE SFP port, 1*10/100/1000BASE-T port, AC power, power adapter) |
| CloudEngine S5731- L4P2HT-RUA | CloudEngine S5731-L4P2HT-RUA (4*10/100/1000BASE-T ports, PoE++, 1*GE hybrid optical- electrical SFP port, 1*10/100/1000BASE-T port, PoE input) |
| CloudEngine S5731- L8T2ST-RUA | CloudEngine S5731-L8T2ST-RUA (8*10/100/1000BASE-T ports, 1*GE SFP port, 1*10/100/1000BASE-T port, AC power, power adapter) |
| CloudEngine S5731- L8P2ST-RUA | CloudEngine S5731-L8P2ST-RUA (8*10/100/1000BASE-T ports, PoE+, 1*GE SFP port, 1*10/100/1000BASE-T port, AC power, power adapter) |
| CloudEngine S5731- L8P2HT-RUA | CloudEngine S5731-L8P2HT-RUA (8*10/100/1000BASE-T ports, PoE+, 1*GE hybrid optical- electrical SFP port, 1*10/100/1000BASE-T port, PoE input) |
| 12W Power adapter | Power adapter for non-PoE models |
| 90W PoE Power adapter 1 | PoE Power adapter with Euroblock connector for S5731-L4P2HW-RUA |
| 90W PoE Power adapter 2 | PoE power adapter for S5731-L4P2S-RUA & S5731-L4P2ST-RUA |
| 150W PoE Power adapter | PoE power adapter for S5731-L4P2HT-RUA & 8-port PoE models |
Huawei S5731-L4T2S-RUA Switch Product Applications
