Description
Cisco UCS B200 M5 Blade Server delivers market-leading performance, versatility, and density for remote locations and data centers to help you handle a wide range of workloads, from network infrastructure to distributed databases.
Cisco UCS B200 M5 Blade Server Product overview
Cisco UCS B200 M5 Blade Server delivers the performance, flexibility, and optimization required for deployment in the data center, cloud, and remote locations. This enterprise-class server delivers market-leading performance, versatility, and density to help you handle a wide range of workloads, including virtual desktop infrastructure (VDI), network infrastructure, distributed databases, converged infrastructure and enterprise Applications such as Oracle and SAP HANA. With programmable, easy-to-use Cisco UCS Manager software and simplified server access (implemented through Cisco SingleConnect technology), the B200 M5 server can quickly deploy stateless physical and virtual workloads. These smart technologies include.
Cisco UCS B200 M5 Blade Server Product picture
Cisco UCS B200 M5 Blade Server Datasheet
| Item | Specs |
| processor | Up to 2 Intel Xeon scalable processors (1 or 2) |
| RAM | 24 DDR4 DIMM slots: 16, 32, 64, and 128 GB at speeds up to 2666 MHz |
| mLOM | Cisco UCS VIC 1340 mLOM Slot |
| Mezzanine adapter (rear) | 1 rear mezzanine adapter for |
| Cisco UCS VIC 1380 Mezzanine Card | |
| Cisco Port Expander Mezzanine Card | |
| Cisco GPU rear mezzanine card | |
| Cisco Blade NVMe Memory Card | |
| Mezzanine adapter (front) | 1 front mezzanine adapter for: |
| Cisco FlexStorage 12 Gbps SAS RAID Controller | |
| Cisco FlexStorage 12 Gbps SAS RAID controller with 1 GB cache | |
| Cisco FlexStorage NVMe or pass-through module | |
| Cisco GPU front mezzanine card | |
| Internal storage | 2 hot-swappable front 2.5-inch drives: |
| HDD: 10,000 or 15,000 rpm with a capacity of 1.8 TB per drive | |
| SSD: SSDs that deliver enterprise-class performance and value with up to 7.6 TB per drive | |
| NVMe: up to 7.7 TB per drive | |
| NOTE: The drive requires a RAID controller or pass-through controller in the front mezzanine adapter slot. | |
| You can choose one of the following: | |
| 2 internal SD cards (32, 64 or 128 GB) | |
| 2 M.2 SATA drives (240 or 960 GB) | |
| Operating temperature | 50 to 95°F (10 to 35°C) |
| Non-operating temperature | -40 to 149°F (-40 to 65°C) |
| Working humidity | 5% to 93%, non-condensing |
| Non-working humidity | 5% to 93%, non-condensing |
| Working elevation | 0 to 3000 meters (0 to 10,000 feet); the maximum ambient temperature is reduced by one degree per liter of 300 meters |
| Non-working elevation | 12,000 meters (40000 feet) |
| Ordering info | Description |
| UCSB-B200-M5 | UCS B200 M5 blade server ，without CPU、RAM、HDD、Mezzanine card |
| UCSB-B200-M5-U | UCS B200 M5 blade server，without CPU、RAM、HDD、Mezzanine card (UPG) |
| UCSB-B200-M5-CH | DISTI：UCS B200 M5，without CPU、RAM Drive slot, HDD, mezzanine card, HS |
Cisco UCS B200 M5 Blade Server Features
The Cisco UCS B200 M4 server is a half-width blade server. Up to eight servers can be deployed in a 6-rack unit (6RU) Cisco UCS 5108 blade chassis, with server density per blade chassis unit being among the highest in the industry. You can configure the B200 M5 to meet local storage needs without having to purchase, cool, and distribute unwanted components.
The B200 M5 offers the following main features:
1st, Up to two Intel scalable CPUs (up to 28 cores per CPU)
2nd, 24 DIMM slots for industry standard DDR4 memory at speeds up to 2666 MHz and up to 3 TB with 128 GB DIMMs.
3rd, Modular onboard LAN (mLOM) card with Cisco UCS Virtual Interface Card (VIC) 1340. The VIC 1340 is a 2-port, 40 Gigabit Ethernet, FCOM mesoscopic adapter that supports Fibre Channel over Ethernet (FCoE).
4th,Optional rear mezzanine VIC with two 40 Gbps unified I/O ports or two sets of 4 x 10 Gbps unified I/O ports providing 80 Gbps connection speed to the server for 10 or 40 Gbps switching fabrics connection
5th, Two optional hot-swappable hard disk drives (HDDs), solid-state disks (SSDs), or NVMe 2.5-inch drives with optional enterprise-class RAID controllers or pass-through controllers
6th, Cisco FlexStorage local drive storage subsystem that provides flexible boot and local storage capabilities and allows you to boot from two mirrored SD cards
7th, Supports up to two optional GPUs
8th, Supports up to one rear storage mezzanine card
Sorry, no attachment available !
