Huawei AP2051DN-E is the latest-generation gigabit wall plate Access Point complying with 802.11ac Wave 2 with built-in smart antennas and support 2 x 2 MIMO and two spatial streams achieving rate of 1.267 Gbit/s
Huawei AP2051DN-E Product Overview
Huawei AP2051DN-E is the gigabit wall plate access points in compliance with 802.11ac Wave 2. With mounting brackets, the product can be easily adapted to junction boxes (86/118/120 mm) and wall-mounting scenarios. साथै, it boasts built-in smart antennas, a hidden indicator, and a brand-new “morning dew” style. These highlights make Huawei AP2051DN-E suitable for environments with densely distributed small rooms, such as hotel guest rooms, student dormitories, hospital wards, and small offices.
Huawei AP2051DN-E Product Pictures
Huawei AP2051DN-E Product Specifications
| ब्रान्ड | Huawei |
| निर्दिष्टीकरणहरू | AP2051DN-E |
| आयामहरू (एच एक्स डब्ल्यू एक्स डी) | 32.5 मिमी x 86 मिमी x 150 mm |
| पावर इनपुट | DC: 45.6V to 57V |
| PoE बिजुली आपूर्ति: In compliance with IEEE 802.3af/at | |
| MIMO: स्थानिय स्ट्रिमहरू | 2 x 2:2 |
| रेडियो प्रोटोकल | 802.11a/b/g/n/ac/ac wave 2 |
| अधिकतम दर | 1.267 Gbit/s |
| एन्टेना प्रकार | Built-in smart antennas |
| बिल्ट-इन ब्लुटुथ | BLE4.1 (supported by the AP2051DN-E) |
| PoE OUT | Supported by AP2051DN-E: Maximum 13.6W (802.3at-compliant, 48वी डीसी, supported only by GE4) |
| सञ्चालन तापमान | 0°C देखि 40°C |
| प्रयोगकर्ताहरूको अधिकतम संख्या | ≤ 256 |
| Maximum Transmit Power | 2.4G: 23 dBm (combined power) |
| 5G: 23 dBm (combined power) | |
| नोट: The actual transmit power depends on local laws and regulations. | |
| अधिकतम पावर खपत | AP2051DN: 11.5डब्लु (excluding the output power of the USB port) |
| AP2051DN-E: 11.5डब्लु (excluding the output power of the USB port and PoE_OUT port) | |
| नोट: वास्तविक अधिकतम बिजुली खपत स्थानीय कानून र नियमहरूमा निर्भर गर्दछ | |
| Interface types | अपलिङ्क: 1 x GE |
| डाउनलिंक: 4 x GE | |
| 2 x Pass-through RJ45 port | |
| 1 x USB port |
Huawei AP2051DN-E Product Features
- 11ac लहर 2 compliance, MU-MIMO (2SU-2MU), delivering services simultaneously on 2.4G and 5G radios, at a rate of up to 400 Mbit/s at 2.4 GHz, 867 Mbit/s Mbit/s at 5 GHz, र 1.267 उपकरणको लागि Gbit/s.
- One GE uplink port, four GE downlink ports, and two RJ45 pass-through phone ports (compatible with RJ11)
- Various installation modes for easy deployment, including ceiling-mounting, wall-mounting, plate-mounting and desk-mounting
- USB port used for external power supply and storage
- Built-in smart antennas, improving the coverage area
- AP2051DN-E: PoE OUT supported by GE4, supplying power for STAs such as IP phones
- AP2051DN-E: बिल्ट-इन ब्लुटुथ, working with eSight to implement Bluetooth device location
- Supports the Fat, फिट, and cloud modes and enables Huawei cloud management platform to manage and operate APs and services on the APs, reducing network O&M लागत
Huawei AP2051DN-E and More AP2051 Models
AP2051DN
AP2051DN-E
AP2051DN-S
AP2051DN-L-S
Huawei AP2051DN-E Product Applications
