Penerangan
SIMCom SIM7600E-PCIE 4G Module is a LTE Cat 1 module in mini PCIE Form factor with LTE-TDD/ LTE-FDD/HSPA+/GSM/GPRS/EDGE etc, supporting maximum 10Mbps downlink rate and 5Mbps uplink rate.
SIMCom SIM7600E-PCIE 4G Module Product Overview
SIMCom SIM7600E-PCIE 4G Module adopts mini PCIE form factor. And AT commands are compatible with SIM7500/SIM7600-H series modules. The module integrates multiple built-in network protocols and supports drivers for main operation systems (Pemacu USB untuk Windows, Linux and Android etc.) dan fungsi perisian. Lebih daripada itu, SIM7600-PCIE integrates main industrial standard interfaces, dengan pengembangan yang kuat, termasuk antara muka yang banyak seperti UART, USB, GPIO. Justeru, the module is suitable for main IoT applications such as telematics, peranti pengawasan dan diagnostik jauh dsb.
SIMCom SIM7600E-PCIE 4G Module Product Pictures
SIMCom SIM7600E-PCIE 4G Module Product Specifications
| Jenama | SIMCom | ||
| produk | SIM7600E-PCIE | ||
| Faktor Bentuk | PCIE mini | ||
| Dimensi(mm) | 50.8*31*5.35 | ||
| Jalur Frekuensi | LTE-FDD | B1/B3/B5/B7/B8/B20 | |
| LTE-TDD | B38/B40/B41 | ||
| WCDMA | B1/B5/B8 | ||
| GSM | 900/1800MHz | ||
| Suhu | -40℃ ~ +85 ℃ | ||
| GNSS | Pilihan | ||
| Voltan bekalan(V) | 3.0~ 3.3 | ||
| Penggunaan kuasa | LTE | 2.3 | |
| WCDMA, | 3.3 | ||
| DRX=9 | |||
| GSM,BS_PA_MFRMS=2 | 2.8 | ||
| LTE(Mbps) | 10(DL)/5(UL) | ||
| HSPA+(Mbps) | 42(DL)/5.76(UL) | ||
| WCDMA(Kbps) | 384(DL)/384(UL) | ||
| GPRS/EDGE(Kbps) | 236.8(DL)/236.8(UL) | ||
| Protokol | TCP/IP/IPV4/IPV6/Multi-PDP/FTP/FTPS/HTTP/ HTTPS/DNS | ||
| Android RIL | Android 5.0/6.0/7.0/8.0/9.0 | ||
| Pemacu USB | Microsoft Windows 7/8/10 | ||
| Linux/Android | |||
| MBIM | Win8/Win10 | ||
| NDIS | Linux/Windows 7/8/10 | ||
| Peningkatan Perisian Tegar | USB/FOTA | ||
| Kad SIM | 1.8V/3.0V | ||
| kawal selia | CE-REDRoHSREACHIMDAGCFDeutsche TelekomVodafone | ||
| Pembawa | Deutsche Telekom/Vodafone | ||
SIMCom SIM7600E-PCIE 4G Module Product Features
- Antara muka Mini-PCIE dengan keserasian yang kuat
- Sokongan penerima GNSS berbilang buruj*
- Sesuai untuk LTE, Rangkaian UMTS dan GSM dengan liputan global
- Fungsi perisian yang banyak: KAKI, LBS, TLS, VoLTE*
- AT commands of the SIM7600-PCIE series are compatible with the SIM7500/SIM7600-H series modules
SIMCom SIM7600E-PCIE 4G Module Product and More Related Models
SIM7600A-PCIE Mini Pcie
SIM7600SA-PCIE Mini Pcie
SIM7600E-PCIE Mini Pcie
SIM7600G-PCIE Mini Pcie
SIM7600NA-PCIE Mini Pcie
SIMCom SIM7600E-PCIE 4G Module Product Applications
