Penerangan
SIMCom A7608SA-H 4G Module is a LTE Cat 4 module with LTE-TDD/ LTE-FDD/HSPA+/GSM/GPRS/EDGE supporting maximum 150Mbps downlink rate and 50Mbps uplink rate.
SIMCom A7608SA-H 4G Module Product Overview
SIMCom A7608SA-H 4G Module adopts LCC+LGA form factor and is compatible with SIM5320/SIM5360 series (UMTS/HSPA+ modules), and SIM7600/SIM7600-H series(LTE modules). Pada masa yang sama, the module supports multiple built-in network protocols, and drivers for main operation systems (Pemacu USB untuk Windows, Linux and Android etc.) dan fungsi perisian, AT commands are compatible with SIM7600 series modules. Lebih-lebih lagi, A7608SA-H integrates main industrial standard interfaces, dengan pengembangan yang kuat, termasuk antara muka yang banyak seperti UART, USB, 2C, GPIO, which is suitable for main IoT applications such as telematics, peranti pengawasan, CPE, penghala industri, dan diagnostik jauh dsb.
SIMCom A7608SA-H 4G Module Product Pictures
SIMCom A7608SA-H 4G Module Product Specifications
| Jenama | SIMCom |
| Model | SIMCom A7608SA-H |
| Faktor bentuk | LCC+LGA |
| Jalur Frekuensi | LTE-TDD B38/B40/B41 LTE-FDD B1/B2/B3/B4/B5/B7/B8/ B20/B28/B66 UMTS/HSPA+ B1/B2/B5/B8 GSM/GPRS/EDGE 850/900/1800/1900 MHz |
| Voltan bekalan | 3.4V~4.2V, Taip: 3.8V |
| Suhu operasi | -40℃ ~ +85 ℃ |
| Dimensi | 30.0*30.0*2.5mm |
| Berat badan | 4.6±0.1g |
| Pemindahan Data | Kucing LTE 4: Uplink up to 50Mbps Downlink up to150Mbps HSPA+: Uplink up to 5.76Mbps Downlink up to 42 Mbps UMTS Uplink/Downlink up to 384Kbps EDGE Uplink/Downlink up to 236.8Kbps GPRS Uplink/Downlink sehingga 85.6Kbps |
| Antara muka | USB2.0 UART (U)kad SIM(1.8V/3V ) PCM Analog audio RMII* PCIE*（Host ModeMMC/SD SDIO* ADC I2C GPIO Antena: Primary/Diversity*/GNSS* |
| Ciri-ciri lain | Pemacu USB untuk Microsoft Windows 7/8/10 Pemacu USB untuk Linux /Android RIL menyokong untuk Android 5.0/6.0/7.0/8.0/9.0 Kemas kini perisian tegar melalui USB/FOTA TCP/IP/IPV4/IPV6/MultiPDP/FTP/FTPS/HTTP/HTTPS/DNS RNDIS/PPP/ECM SMS SSL |
| Pensijilan | RCM#/Anatel#/RoHS#/REACH# |
SIMCom A7608SA-H 4G Module Product Features
LCC+LGA form factor with abundant interfaces
Sesuai untuk LTE, UMTS and GSM networks
Fungsi perisian yang banyak: KAKI, LBS, SSL
The AT commands of A7608SA-H are compatible with SIM7600 series modules
SIMCom A7608SA-H 4G Module and More Related Models
A7672G LCC+LGA
A7670E LCC+LGA
A7608SA-H LCC+LGA
A7676E LCC+LGA
A7672X LCC+LGA
A7682E LCC+LGA 85Pin
A7602X-H(E/SA) LCC+LGA 163Pin
A7600E-H LCC+LGA
A7600C1 LCC+LGA 119Pin
SIM7600G R2 LCC+LGA
SIM7600G-H R2 LCC+LGA
A7600E LCC+LGA
SIM7600X LCC/LCC+LGA 87/119Pin
SIM7500X LGA 56Pin
SIM7600X-H-PCIE Mini Pcie
SIM7600X-PCIE Mini Pcie
SIM7600X-H LCC/LCC+LGA 87/119Pin
SIM7600X-H-M2 M.2
Pcie Mini Siri SIM7500-PCIE
SIMCom A7608SA-H 4G Module Product Applications
