Penerangan
Huawei R4805G1 Rectifier Module is a digital rectifier that converts the 85~300VAC to 53.5VDC
Huawei R4805G1 Rectifier Module Product Overview
Huawei R4805G1 Rectifier Module is a digital rectifier that converts the 85~300VAC to 53.5VDC . the module features the characters of high efficiency, permulaan berjalan kaki, palam panas, perlindungan yang lengkap, and no audible noise. Lebih-lebih lagi, Penerus menggunakan teknologi pemantauan kuasa terkini, and implements the function of monitoring the states of loads and the rectifier status in real time. Voltan keluaran penerus boleh dilaraskan melalui hos.
Huawei R4805G1 Rectifier Module Product Pictures
Huawei R4805G1 Rectifier Module Product Specifications
| Jenama | Huawei |
| Model | R4805G1 |
| Voltan masukan | 85~300VAC |
| Input voltage mode | 220VAC single phase (or 110VAC dual live lines) |
| Kekerapan | 45~65Hz Rated: 50Hz/60Hz |
| Arus input maksimum | ≤2.5A |
| Faktor kuasa | ≥0.98 |
| THD | ≤6％ |
| Voltan keluaran | 42~58VDC Nilai lalai: 53.5VDC |
| Kuasa output | 270W(176~300VAC) |
| Dimensi | 40.8(H)mm×95.5(W)mm×208(D)mm |
| Berat badan | ≤1.3kg |
| Menyejukkan | Penyejukan semula jadi |
| Suhu Operasi | -40℃~+75℃(non-derating under 55℃) |
| Suhu penyimpanan | -40℃~+70℃ |
| Kelembapan relatif | 5% ~ 95%(tidak berkondensasi) |
| Input overvoltage protection | Protection point: >300VAC |
| Input undervoltage protection | Protection point: <85VAC |
| Output overvoltage protection | 58.5~60.5VDC(can be set by PMU) |
| Output short circuit protection | A long term short circuit is allowed. |
| Over-temperature protection | Protection point: over 75℃(167℉). |
| MTBF | >500,000Jam |
| Spesifikasi | No audible noise |
| Safety | Passes TUV,CE,pensijilan UL. |
| Perlindungan kilat | YD 5098-2005 5KA |
| Pensijilan | Catch the CB certificate. Complies with UL60950-1 IEC60950-1 EN60950-1 CAN/CSA C22.2 No. 60950 -1 |
| EMC | EN55022 Class B EN55024 EN61000-3-2 EN61000-3-3 ETSI EN300 386 ETSI EN301489 ITU-T K.20 |
Huawei R4805G1 Rectifier Module Product Features
- Kecekapan tinggi: ≥96％
- Julat voltan masukan: 85~300VAC
- Julat suhu operasi: -40℃~75℃
- Herotan harmonik total(THD): ≤5％
- Palam panas
- Kawalan digital
- Meter elektrik pintar
- Communication over CAN
- Pelarasan voltan dan arus
- Memenuhi keperluan RoHS
- Lulus TUV,CE,CB,pensijilan UL
Huawei R4805G1 Rectifier Module and More Related Models
| Nombor Bahagian | Voltan Masukan | Voltan Keluaran | Kuasa output | Kecekapan | Suhu Operasi |
| R4805G1 | 85-300Vac | 42-58Vdc | 270W | 94 % | -40C hingga +75C |
| R4815G1 | 85-300Vac | 42-58Vdc | 870W | 96 % | -40C hingga +75C |
| R4815N1 | 85-300Vac | 42-58Vdc | 1000W | 94 % | -40C hingga +75C |
| R4830G1 | 85-300Vac | 42-58Vdc | 1600W | 96 % | -40C hingga +75C |
| R4830G2 | 85-300Vac | 42-58Vdc | 2000W | 96 % | -40C hingga +75C |
| R4830N2 | 85-300Vac | 42-58Vdc | 1605W | 94 % | -40C hingga +75C |
| R4850G1 | 85-300Vac | 42-58Vdc | 3000W | 96 % | -40C hingga +75C |
| R4850G2 | 85-300Vac | 42-58Vdc | 3000W | 96 % | -40C hingga +75C |
| R4850N1 | 85-300Vac | 42-58Vdc | 2900W | 92 % | -40C hingga +75C |
| R4850N2 | 85-300Vac | 42-58Vdc | 3000W | 94 % | -40C hingga +75C |
| R48100G1 | 260-530Vac | 42-58Vdc | 6000W | 96 % | -40C hingga +75C |
| R33640G1 | 260-530Vac | 300-400Vdc | 15kW | 97% | -40C hingga +75C |
| R50030G1 | 260-456Vac | 300-500Vdc | 15kW | 95.8% | -30C hingga +65C |
Huawei R4805G1 Rectifier Module Product Applications
