Nokia G-010G-A FTTH

SKU: Nokia G-010G-A FTTH Kategorija: Tagi: ,

Apraksts

Nokia G-010G-A FTTH is an optical terminal unit with 1GE port delivering premium service experience for all services, and applied for business offices, hospitals, hospitality, real estate developers and other organizations

Nokia G-010G-A FTTH Product Overview

Nokia I-010G-A FTTH is designed to deliver gigabit speeds in an Optical LAN environment. The ONT G-010G-A provides a Gigabit Ethernet (Sasmalciniet) user interfaceand delivers premium service experience for all services, including data and video. This ONT terminates a full standard compliant Gigabit Passive Optical Network (GPON) fiber interface. ONT G-010G-A is applied for business offices, hospitals, hospitality, real estate developers and other organizations that need high capacity LAN to support a new generation of services, improve productivity and build a competitive edge. ONT G-010G-A is suitable for indoor deployments and can be mounted on the desktop,wall or ceiling. The ONT supports a 1Gb/s upstream and 1Gb/sdownstream line rate. It is compatible with Nokia 7360 ISAM FXaccess node and managed through the Nokia 5571 Passive OpticalLAN Command Center (PCC)

Nokia G-010G-A FTTH Product Pictures

NOKIA I-010G FTTHNOKIA I-010G FTTH

NOKIA I-010G FTTHNOKIA I-010G FTTH

Nokia G-010G-A FTTH Product Specifications

Lieta G-010G-A
User-side port 1xGE
GPON port Class C+ Module
Network-side port GPON (SC/UPC)
Drošība MAC Filter
Elektrības patēriņš Statiskā jauda: 2 W
Maksimālais enerģijas patēriņš: 2.5 W
Jaudas specifikācijas Strāvas adaptera ieeja: 100 uz 240 V AC, 50-60 Hz
Sistēmas barošanas avots: 11-14 V līdzstrāva, 0.5 A
Izmēri (garums x platums x augstums) 82 mm x 90 mm x 27 mm
Svars Par 0.5 Kilograms
Darba vide Darbības temperatūra: 0ºC līdz 40ºC
Vides mitrums: 5% uz 95% (nekondensējošs)
Pressure environment: 0 uz 106 kPa
Augstums virs jūras līmeņa: 3000 m

Nokia G-010G-A FTTH Product Features

  • Interfeiss: One 10/100/1000Base-T RJ-45
  • Compliant with OMCI standard (ONT pārvaldības vadības interfeiss)
  • Remotely managed by the Alcatel-Lucent 5520 AMS Network Management System
  • Wire speed data transfer for all packet sizes
  • Per-subscriber, per-service bandwidth control
  • IP video with IGMPv2 and IGMPv3
  • Support of Received Signal Strength Indication (RSSI) for lean operations and remote troubleshooting
  • 984 compliant
  • Wall and desktop mounting

Nokia G-010G-A FTTH ad More FTTH Models

G-010G-P GPON 1 GE ports
es-010G GPON 1 GE ports
G-010G GPON 1 GE ports
G-140W-MH GPON 1*GE+3*FE+1*POTS+1*USB+2,4G WIFI, 3dBi
G-140W-MD GPON 1*GE+3*FE+WIFI
G-140W-ME GPON 4*GE+1*POTS+2*USB+2.4G/5G WIFI
G-140W-MF GPON 4*GE+1*POTS+2*USB+2.4G/5G WIFI
G-140W-C GPON 4*GE+1*POTS+2*USB+2.4G/5G WIFI
G-1425-MA GPON 4*GE+1*POTS+2*USB+2.4G/5G WIFI
G-1426-MA GPON 4GE+2USB+1POTS+2.4G/5G Divjoslu WI-FI 6 AX1800
HA-020W-C Divjoslu WiFi 5 Bezvadu AP mājas maršrutētājs

Nokia G-010G-A FTTH Product Applications
