Apraksts
Huawei S6735-S48X6C Switch is a high-performance full 10 Gigabit Ethernet switch with 48 *10 Gigabit SFP+, 6 x 100GE QSFP28, bez barošanas avota
Huawei S6735-S48X6C Switch Product Overview
Huawei S6735-S48X6C is a high-performance all-10G Gigabit Ethernet switch for next-generation enterprise network architectures. It provides 48 x 10GE SFP+ porti, 6 x 40GE/100GE QSFP28 porti, un atbalsta 1+1 power backup with Packet forwarding rate: 1620Mpps un komutācijas jauda: 2.56T/25,6 Tbps. With rich service features, perfekta drošības kontrole, vienkārša darbība un apkope, un nobriedušas IPv6 funkcijas, the switch can be widely used in various application scenarios such as enterprise campus core and aggregation, and data center access.
Papildus, S6735-S48X6C not only supports the traditional STP/RSTP/MSTP spanning tree protocol, but also support Huawei’s self-innovative SEP intelligent Ethernet protection technology and the industry’s latest Ethernet ring standard ERPS. SEP ir gredzenveida tīkla protokols, kas paredzēts Ethernet saites slānim, which is suitable for various networking such as half-ring, viss gredzens, and hierarchical linkage, and its protocol is simple and reliable, convenient for maintenance, and provides 50ms fast service switchover. ERPS is ITU-T’s G.8032 standard, which enables fast protection switching in milliseconds for Ethernet rings based on traditional Ethernet MAC and bridge functions.
Huawei S6735-S48X6C Switch Product Pictures
Huawei S6735-S48X6C Switch Product Specifications
| Lieta | Sīkāka informācija |
| Apraksts | S6735-S48X6C (48*10GE SFP+ porti, 6*100GE QSFP28 porti, without power modules) |
| Daļas numurs | 98011879 |
| Modelis | S6735-S48X6C |
| Pirmā atbalstītā versija | V200R021C00SPC600 |
| Izmēri ar iepakojumu (AxPxD) [mm(iekšā.)] | 175 mm x 650 mm x 550 mm (6.89 iekšā. x 25.59 iekšā. x 21.65 iekšā.) |
| Šasijas augstums [U] | 1 U |
| Svars bez iepakojuma [Kilograms(Mārciņas)] | 6.24 Kilograms (13.76 Mārciņas) |
| Svars ar iepakojumu [Kilograms(Mārciņas)] | 8.0 Kilograms (17.64 Mārciņas) |
| Tipisks enerģijas patēriņš [W] | 168 W |
| Tipiska siltuma izkliede [BTU/stundā] | 573.23 BTU/stundā |
| Maksimālais enerģijas patēriņš [W] | 318 W |
| Maksimālā siltuma izkliede [BTU/stundā] | 1085.05 BTU/stundā |
| Statiskais enerģijas patēriņš [W] | 106 W |
| MTBF [gadā] | 36.57 gadā |
| MTTR [stunda] | 2 stunda |
| Pieejamība | >0.99999 |
| Troksnis normālā temperatūrā (akustiskā jauda) [dB(A)] | 60.6 (Maiņstrāvas barošanas avots) |
| 64.3 (Līdzstrāvas barošanas avots) | |
| Troksnis normālā temperatūrā (akustiskais spiediens) [dB(A)] | 48.4 dB(A) |
| Liekais barošanas avots | 1+1 Pluggable AC and DC power modules can be used together in the same switch. |
| Ilgstoša darba temperatūra [°C(°F)] | –5°C to +45°C (23°F līdz 113 °F) augstumā 0 uz 1800 m (0 uz 5905.51 pēdas) |
| Uzglabāšanas temperatūra [°C(°F)] | -40°C līdz +70°C (–40°F līdz +158°F) |
| Ilgstoša ekspluatācijas relatīvais mitrums [RH] | 5% RH līdz 95% RH (nekondensējošs) |
| Ilgtermiņa darbības augstums [m(pēdas)] | 0–5000 m (0–16404 ft.) |
| Uzglabāšanas augstums [m(pēdas)] | 0–5000 m (0–16404 ft.) |
| Barošanas režīms | Pluggable power supply |
| Nominālais ieejas spriegums [V] | Maiņstrāvas ieeja: 100 V AC uz 240 V AC, 50/60 Hz |
| High-voltage DC input: 240 V DC | |
| Līdzstrāvas ieeja: –48 V DC to –60 V DC | |
| Ieejas sprieguma diapazons [V] | Maiņstrāvas ieeja: 90 V AC uz 290 V AC; 45 Hz līdz 65 Hz |
| High-voltage DC input: 190 V DC līdz 290 V DC | |
| Līdzstrāvas ieeja: –38.4 V DC to –72 V DC | |
| Maksimālā ieejas strāva [A] | The current specifications depend on the pluggable power modules in use. Sīkāka informācija, see the related power module specifications. |
| Atmiņa | 4 GB |
| Zibatmiņa | The physical space is 8 GB. You can run the display version command to view the actual available space. |
| Siltuma izkliedes režīms | Air cooling heat dissipation and intelligent speed adjustment |
| Gaisa plūsmas virziens | Air intake from front and air exhaust from rear |
| PoE | Nav atbalstīts |
| Sertifikācija | EMC sertifikācija |
| Drošības sertifikācija | |
| Ražošanas sertifikācija |
Huawei S6735-S48X6C Switch Product Features
- The switch has the industry’s leading 10 Gigabit port density and switching capacity of the same grade equipment, and a single device can support up to 48 10 Gigabit ports with full line-speed forwarding and up to 6 100GE QSFP28 ports to meet the needs of extremely fast transmission.
- This series of switches supports perfect Layer 2 un Slānis 3 multiraides protokoli, and supports PIM SM, PIM DM, PIM SSM, MLD, IGMP SNOOPING, to meet the needs of multi-terminal HD video surveillance and video conference access.
- The switch supports Layer 3 features such as OSPF, ISIS, BGP, VRRP, utt., to meet the requirements of enterprise access and aggregation service bearer, and support richer voice, video, un datu lietojumprogrammas.
- The switch supports unified user management functions, aizsargā piekļuves slāņa ierīču iespēju un piekļuves metožu atšķirības, supports multiple authentication methods such as 802.1X/MAC/Portal, supports grouping/domain/time-sharing management of users, and provides users with a consistent service experience across the network, realizing a leap from “device management-centric” uz “user-centered”*.
- The switch supports complete DoS anti-attack and user-type anti-attack. Starp viņiem, DoS anti-attacks are mainly aimed at attacks on the switch itself, tostarp SYN Flood, Zeme, Smurfs, and ICMP Flood; User class prevention attacks involve DHCP server phishing attacks, IP/MAC viltošana, DHCP pieprasījuma plūdi, and changes DHCP CHADDR values and so on.
Huawei S6735-S48X6C Switch Product Ordering Info
| Produkta modelis | Produkta apraksts |
| CloudEngine S6735-S24X6C | S6735-S24X6C (24 x 10 Gigabit SFP+, 6 x 100GE QSFP28, bez barošanas avota) |
| CloudEngine S6735-S48X6C | S6735-S48X6C (48 10 Gigabit SFP+, 6 x 100GE QSFP28, bez barošanas avota) |
| FAN-031A-B | Ventilatora modulis (priekšējā un aizmugurējā ventilācija) |
| PAC600S12-CB | 600W Maiņstrāvas barošanas modulis |
| PDC1000S12-DB | 1000W līdzstrāvas barošanas modulis |
| L-VxLAN-S67 | S67 sērija, VxLAN programmatūras licence katrai ierīcei |
| L-MLIC-S67S | S67XX-S pamata programmatūra, katrai ierīcei |
| N1-S67S-M-Lic | N1-S67XX-S pamata programmatūra, katrai ierīcei |
| N1-S67S-M-SnS1Y | S67XX-S pamata programmatūras programmatūras abonēšana un garantētā gada maksa, 1 gadā par ierīci |
| N1-S67S-F-Lic | N1-Intent-Driven Campus pamata pakotne, S67XX-S, katrai ierīcei |
| N1-S67S-F-SnS | N1-Intent-Driven Campus pamata pakotne, S67XX-S programmatūras abonēšanas un ikgadējās garantijas maksa, katrai ierīcei |
| N1-S67S-A-Lic | N1-Intent-Driven Park Premium pakotne, S67XX-S, katrai ierīcei |
| N1-S67S-A-SnS | N1-Intent-Driven Park Premium pakotne, S67XX-S, Programmatūras abonements & Garantētā gada maksa, katrai ierīcei |
| N1-S67S-FToA-SnS | N1-Intent-Driven Campus Basic pakotne jaunināta uz Premium pakotni, S67XX-S, programmatūras abonēšanas un ikgadējās garantijas maksa, katrai ierīcei |
| N1-S67S-FToA-Lic | N1-Intent-Driven Campus Basic pakotne jaunināta uz Premium pakotni, S67XX-S, katrai ierīcei |
Huawei S6735-S48X6C Switch Product Applications
