Huawei ME60-X8ルーター

説明

Huawei ME60-X8 Router is a multi-service control gateway product (ie BRAS) launched by Huawei. It is mainly used in radio, television, education and other industries to provide unified user access and management platform.

Huawei ME60-X8 Router Product Overview

Huawei ME60-X8 Router is based on the 400G / 1T platform and provides 1T boards to realize large-capacity service carrying and meeting future bandwidth growth requirements. 同時に, Huawei ME60-X8 Router is based on the existing VRP software platform and is fully compatible with all line cards on the existing network. The whole machine uses high-density ports and compact design, which can effectively save space.

Huawei ME60-X8 Router supports IPv6 routing protocols, including static routing, OSPFv3, IS-ISv6, and BGP4 +. It supports IPv6 terminal access, IPv6 access control lists, and IPv6-based policy routing. Huawei ME60-X8 Router also provides large-capacity IPv6 FIBs, which can be implemented in the future. Smooth evolution to IPv6. Huawei ME60-X8 also supports IPv4 and IPv6 dual protocol stacks and IPv4 / IPv6 transition technologies to solve the interworking between IPv6 and IPv4 and the interworking between IPv6 islands and enhance network scalability.

Huawei ME60-X8 Router Product Pictures

Huawei ME60-X8 Router Product Specifications

Huawei ME60-X8 Router Product Features

• スケーラブル, non-blocking switching network with switching capacity on the order of Tbit;
• Adopt distributed hardware forwarding technology, fast business deployment capability;
• Compact overall structure to increase port density; Normalized design of the whole machine components
• Control channels, business channels, and monitoring channels are completely separated to ensure the smooth flow of control channels and monitoring channels; carrier-class high reliability and manageability
• The system adopts module-level shielding, which fully meets the EMC (ElectroMagnetic Compatibility) 要件; single boards, パワーモジュール, and fans support hot-plugging;
  Innovative U-shaped air duct design to improve the cooling capacity of the system
• District power supply to improve the power supply capacity of a single frame; Use 200mm fan design, add fan filter box, support NEBS, and ETSI; The main control board SRU (Switch Router Unit) adopts 1: 1 redundant backup
• Switch fabric SFU load-sharing redundant backup; 電源, ファン, 時計, management bus, and other key components achieve redundant backup.
• Provide single-board protection against MIS insertion to avoid failure due to incorrect slot insertion.
• Provide voltage and ambient temperature alarm prompt information, alarm indication, running status and alarm status query.

Huawei ME60-X8 Router Product Ordering Info

Huawei ME60-X8 Router Product Applications
