Keterangan
DAC QSFP-40G-CU7M high-speed cable offers low power consumption and low latency, menjadikannya solusi ideal untuk transmisi jarak pendek (hingga 7m) antar rak pusat data, dan secara efektif dapat menghemat biaya dibandingkan dengan kombinasi modul dan kabel patch
DAC QSFP-40G-CU7M Product Overview
DAC QSFP-40G-CU7M is a Cisco, Huawei compatible direct-attach copper QSFP+ cable, which is designed, programmed and tested to work with brand compatible switches and routers and complies with MSA industry standards.
This passive Twinax copper cable supports 40 Gigabit Ethernet applications connected through QSFP+ (Mini-GBIC) pelabuhan. This copper QSFP+ cable is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
Designed for high-speed performance, this low-power, low-latency QSFP+ cable is a cost-effective alternative to fiber-optic cable assemblies, supporting short-distance applications such as point-to-point in-rack network switch or server connections.
DAC QSFP-40G-CU7M Product Pictures
DAC QSFP-40G-CU7M Product Specifications
| Barang | Keterangan |
| Model | QSFP-4SFP10G-CU7M |
| Tipe Konektor | QSFP+ to 4 SFP+ |
| Kecepatan Data Maks | 40Gbps |
| Radius Tikungan Minimum | 30mm |
| Kawat AWG | 26AWG |
| Panjang kabel | 7M(22.96kaki) |
| Bahan Jaket | PVC (OFNR) |
| Suhu | 0 hingga 70°C (32 hingga 158°F) |
| Protokol | 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Saluran Serat |
DAC QSFP-40G-CU7M Product Features
- Compliant with SFF- 8436
- Up to 10.3125Gbps data rate per channel
- Up to 7m transmission
- Catu daya 3.3V tunggal
- Sesuai RoHS
- Kisaran suhu komersial(com): 0 hingga 70°C
- Konsumsi daya rendah: less than 0.1W
- High-Density QSFP 38-PIN Connector
- 40 Gigabit Ethernet
- Saluran Fibre melalui Ethernet
DAC QSFP-40G-CU7M Product and More DAC Cables
| Model | Panjang | Atribut listrik | Radius Tikungan | Tipe Konektor |
| SFP-10G-CU1M | 1 M | Pasif | 25 mm | SFP+ to SFP+ |
| SFP-10G-CU2M | 2 M | Pasif | 25 mm | SFP+ to SFP+ |
| SFP-10G-CU3M | 3 M | Pasif | 25 mm | SFP+ to SFP+ |
| SFP-10G-CU5M | 5 M | Pasif | 30 mm | SFP+ to SFP+ |
| SFP-10G-AC10M | 10 M | Active | 25 mm | SFP+ to SFP+ |
| QSFP-40G-CU1M | 1 M | Pasif | 35 mm | QSFP+ to QSFP+ |
| QSFP-40G-CU3M | 3 M | Pasif | 40 mm | QSFP+ to QSFP+ |
| QSFP-40G-CU5M | 5 M | Pasif | 45 mm | QSFP+ to QSFP+ |
| QSFP-4SFP10G-CU1M | 1 M | Pasif | 25 mm | QSFP+ to 4*SFP+ |
| QSFP-4SFP10G-CU3M | 3 M | Pasif | 25 mm | QSFP+ to 4*SFP+ |
| QSFP-4SFP10G-CU5M | 5 M | Pasif | 30 mm | QSFP+ to 4*SFP+ |
| QSFP28-100G-CU1M | 1 M | Pasif | 70 mm | QSFP28 hingga QSFP28 |
| QSFP28-100G-CU3M | 3 M | Pasif | 70 mm | QSFP28 hingga QSFP28 |
| QSFP28-100G-CU5M | 5 M | Pasif | 70 mm | QSFP28 hingga QSFP28 |
| SFP-25G-CU1M | 1 M | Pasif | 35 mm | SFP28 to SFP28 |
| SFP-25G-CU3M | 3 M | Pasif | 35 mm | SFP28 to SFP28 |
| SFP-25G-CU3M-N | 3 M | Pasif | 40 mm | SFP28 to SFP28 |
| SFP-25G-CU5M | 5 M | Pasif | 40 mm | SFP28 to SFP28 |
DAC QSFP-40G-CU7M Product Applications
