Նկարագրություն
Huawei S5755-H24U4Y2CZ Switch is a 24×10/100/1000 Base-T Ethernet ports, 4×1/10/25GE SFP28, 2 x 40/100GE QSFP28 ports and supporting 60W PoE++
Huawei S5755-H24U4Y2CZ Switch Product Overview
It is a high-quality gigabit access switch based on Huawei’s unified software platform. Huawei S5755-H24U4Y2CZ creates a multi-purpose network through VXLAN-based network virtualization. Ի հավելումն, the switch also stands out for free mobility that delivers consistent user experience anywhere, anytime. Առավելագույնը 48 downlink ports and MACsec support on all ports make CloudEngine S5755-H the best choice of access switches for the Wi-Fi 6 and Wi-Fi 7 դարաշրջան. With these merits, S5755-H series can be widely used in healthcare, մանրածախ, հանքարդյունաբերություն, Ինտերնետ Ծառայությունների Մատակարար (ISP), and other industries. Ավելին, CloudEngine S5755 H supports the iStack function that combines multiple switches into a logical switch. Member switches in a stack implement redundancy backup to improve device reliability and use inter device link aggregation to improve link reliability. iStack-ն ապահովում է ցանցի մեծ մասշտաբայնություն. You can increase a stack’s ports, թողունակություն, and processing capacity by simply adding member switches. istack- ը նաեւ պարզեցնում է սարքի կազմաձեւերը եւ կառավարումը. Afte r a stack is set up, up to nine physical switches can be virtualized into one logical device. Կարող եք մուտք գործել ցանկացած անդամի անջատիչ, որպեսզի աշխատեք բոլոր անդամ անջատիչները.
Huawei S5755-H24U4Y2CZ Switch Product Pictures
Huawei S5755-H24U4Y2CZ Switch Product Specifications
Ապրանքի մոդել | CloudEngine S5755-H24T4Y2CZ | CloudEngine S5755-H24P4Y2CZ | CloudEngine S5755-H24U4Y2CZ | CloudEngine S5755-H48T4Y2CZ | CloudEngine S5755-H48P4Y2CZ | CloudEngine S5755-H48U4Y2CZ |
Փոխանցման կատարում | 450MPs | 450MPs | 450MPs | 450MPs | 450MPs | 450MPs |
Անջատիչ հզորություն2 | 648 GBPS / 2.32 TBPS | 648 GBPS / 2.32 TBPS | 648 GBPS / 2.32 TBPS | 696 GBPS / 2.32 TBPS | 696 GBPS / 2.32 TBPS | 696 GBPS / 2.32 TBPS |
Ֆիքսված նավահանգիստներ | 24 × 10/100/1000 Base-T Ethernet պորտեր, 4 x 1/10/25GE SFP28, 2 x 40/100GE QSFP28 ports | 48 × 10/100/1000 Base-T Ethernet պորտեր, 4 x 1/10/25GE SFP28, 2 x 40/100GE QSFP28 ports | ||||
PoE | | Աջակցված է, PoE+ | Աջակցված է, 60W PoE++ | | Աջակցված է, PoE+ | Աջակցված է, 60W PoE++ |
Էլեկտրաէներգիայի մատակարարման տեսակը | 1+1 power supply backup | 3 էլեկտրամատակարարումներ, N+1 power supply backup | 3 էլեկտրամատակարարումներ, N+1 power supply backup | 1+1 power supply backup | 3 էլեկտրամատակարարումներ, N+1 power supply backup | 3 էլեկտրամատակարարումներ, N+1 power supply backup |
Expanded Card Slot | Reserved expanded card slot | |||||
MAC-ի առանձնահատկությունները | IEEE 802.1d համապատասխանություն | |||||
MAC հասցեի ավտոմատ ուսուցում և ծերացում | ||||||
Ստատիկ, դինամիկ, և սև խոռոչի MAC հասցեի մուտքերը | ||||||
Փաթեթների զտում` հիմնված աղբյուրի MAC հասցեների վրա | ||||||
iPCA | Ծառայությունների փաթեթների ուղղակի գունավորում` կորցրած փաթեթների քանակի և փաթեթների կորստի հարաբերակցության վերաբերյալ իրական ժամանակում վիճակագրություն հավաքելու համար | |||||
Collecting real-time statistics on the number of lost packets and packet loss ratio at network and device levels | ||||||
VXLAN | VXLAN Layer 2 և Շերտ 3 gateways | |||||
Կենտրոնացված և բաշխված դարպասներ | ||||||
BGP-EVPN | ||||||
Կազմաձևված է NETCONF արձանագրության միջոցով | ||||||
Փոխգործունակություն | VBST (համատեղելի է PVST/PVST+/RPVST-ի հետ) | |||||
LNP (նման է DTP-ին) | ||||||
VCMP (նման է VTP-ին) |
Huawei S5755-H24U4Y2CZ Switch Product Features
- Provide excellent quality of service(QoS) Հնարավորություններ եւ աջակցում է հերթի պլանավորման եւ գերբնակված կառավարման ալգորիթմներին. Լրացուցիչ, it adopts innovative priority queuing and multi level scheduling mechanisms to implement fine grained scheduling of data flows, meetin g service quality requirements of different user terminals and services.
- Support Smart Link and Virtual Router Redundancy Protocol (VRRP), որոնք իրականացնում են վերբեռնման կրկնօրինակում. One S575 5 H switch can connect to multiple aggregation switches through multiple links, զգալիորեն բարելավելով մուտքի սարքերի հուսալիությունը.
- Ստեղծեք և պահպանում է DHCP snooping պարտադիր աղյուսակը, և հեռացնում է այն փաթեթները, որոնք չեն համապատասխանում աղյուսակի գրառումներին. Դուք կարող եք նշել DHCP-ի վստահելի և անվստահելի նավահանգիստները, որպեսզի համոզվեք, որ օգտվողները միանում են միայն լիազորված DHCP սերվերին:.
- Developed based on the mature, stable platform and supports I Pv4/IPv6 dual stacks, IPv6 երթուղղման արձանագրություններ (RIPng, OSPFv3, BGP4+, and IS IS for IPv6). Այս IPV6 առանձնահատկություններով, the CloudEngine S5755 H can be deployed on a pure IPv4 network, Մաքուր IPv6 ցանց, կամ ընդհանուր IPV4 / IPV6 ցանց, helping achieve IPv4 to I Pv6 tran
Huawei S5755-H24U4Y2CZ Switch Product Applications
