Leírás
Huawei S6750-H48Y8C Switch is a next-generation enterprise-class core and aggregation switch, which offers 48 x 1/10/25 GE SFP28, 8 x 40/100 GE QSFP28 portok, 1+1 power backup and Switching capacity: 4Tbps/ 8Tbps
Huawei S6750-H48Y8C Switch Product Overview
The switch offers high performance, magas megbízhatóság, clo ud management, and intelligent operations and maintenance (O&M). They build on an industry leading software and hardware platform and are purpose built with security, IoT, and cloud in mind. With these traits, S6750-H48Y8C can be widely used in ente rprise campuses, colleges/universities, data centers, and other scenarios. Továbbá, S6750-H series 25GE switches offer 25GE port types, flexibly adapting to diversified network bandwidth requirements. They also support cloud management and implement clo ud managed network services throughout the full lifecycle from planning, bevetése, megfigyelés, experience visibility, és hibajavítás, all the way to network optim ization, jelentősen leegyszerűsíti a hálózatkezelést. The product also supports free mobility, enables consistent user experience no matter the user location or IP address, fully meeting enterprises’ demands for mobile offices.
Huawei S6750-H48Y8C Switch Product Pictures
Huawei S6750-H48Y8C Switch Product Specifications
| termék modell | CloudEngine S6750-H36C |
| Kapcsolási kapacitás2 | 7.2Tbps/ 8Tbps |
| Fix portok | 32 × 40/100 Gig QSFP+, 4 x 40/100 Gig QSFP ports* |
| *jegyzet：In the future, 4 x 200G optical ports will be supported for uplink ports. | |
| Power Supply Type | 1+1 tápellátás tartalék |
| MAC jellemzők | MAC-cím automatikus tanulása és öregítése |
| Statikus, dinamikus, és blackhole MAC-cím bejegyzéseket | |
| Csomagszűrés a forrás MAC-címek alapján | |
| MAC address learning limiting based on ports and VLANs | |
| VXLAN Features | Distributed and centralized VXLAN gateways |
| BGP EVPN | |
| VXLAN configuration through NETCONF | |
| VXLAN to the access and aggregation layers | |
| iPCA quality awareness | Direct marking of service packets to obtain real-time statistics about dropped packets and packet loss rate |
| Statistics about dropped packets and packet loss rate on Layer 2/Layer 3 networks and devices | |
| QoS | Traffic classification based on information from the link layer to the application layer |
| Complete queue scheduling and congestion control algorithms | |
| Accurate multi-level scheduling for data flows | |
| Hardware-based low-latency QoS queues for multicast packets | |
| Interoperabilitás | VBST (kompatibilis a PVST/PVST+/RPVST-vel) |
| LNP (hasonló a DTP-hez) | |
| VCMP (hasonló a VTP-hez) |
Huawei S6750-H48Y8C Switch Product Features
- S6750-H series 25GE switches support fully customizing the forwarding mode, továbbítási magatartás, és a forgalom keresési algoritmusa. Az új szolgáltatások mikrokódos programozással valósulnak meg. Az ügyfeleknek nem kell új hardvert cserélniük, és az új szolgáltatások hat hónapon belül bevezethetők.
- S6750-H series 25GE switches provide open interfaces and user-defined forwarding processes to meet customized service requirements of enterprises. Enterprises can use multi-layer open interfaces to develop new protocols and functions independently. They can also hand over their requirements to vendors and jointly develop them to build an enterprise dedicated campus network.
- S6750-H series switches provide excellent quality of service(QoS) capabilities and supports queue scheduling and congestion control algorithms. Továbbá, it adopts innovative priority queuing and multi-level scheduling mechanisms to implement fine-grained scheduling of data flows, meeting service quality requirements of different user terminals and services.
- S6750-H series 25GE switches support Smart Link and Virtual Router Redundancy Protocol (VRRP), amelyek megvalósítják a felfelé irányuló kapcsolatok biztonsági mentését. One CloudEngine S6750-H series switch can connect to multiple core switches through multiple links, significantly improving reliability of aggregation devices.
Huawei S6750-H48Y8C Switch Ordering Info
| Modell | termékleírás |
| CloudEngine S6750H48Y8C | CloudEngine S6750-H48Y8C (48*25GE SFP28 ports, 8*100GE QSFP28 portok, tápmodul nélkül) |
| PAC600S12-PB | 600W AC tápmodul |
| PAC1K2S12-PB | 1200W AC tápmodul |
| PDC1K2S12-CE | 1200W DC tápmodul |
| VENTILÁTOR-031A-B | Ventilátor modul |
| Engedély | termékleírás |
| N1-S67H-M-Lic | S67XX-H Series Basic SW,Készülékenként |
| N1-S67H-M-SnS1Y | S67XX-H Series Basic SW,SnS,Készülékenként,1Év |
| N1-S67H-F-Lic | N1-CloudCampus,Alapítvány,S67XX-H sorozat,Készülékenként |
| N1-S67H-F-SnS | N1-CloudCampus,Alapítvány,S67XX-H sorozat,SnS,Készülékenként |
| N1-S67H-A-Lic | N1-CloudCampus,Fejlett,S67XX-H sorozat,Készülékenként |
| N1-S67H-A-SnS | N1-CloudCampus,Fejlett,S67XX-H sorozat,SnS,Készülékenként |
| Engedély | termékleírás |
| N1-S67H-FToA-Lic | N1-Upgrade-Foundation to Advanced,S67XX-H,Készülékenként |
| N1-S67H-FToA-SnS | N1-Upgrade-Foundation to Advanced,S67XX-H,SnS,Készülékenként |
| N1-AM-30-Lic | N1-CloudCampus, Add-On Package, Access Management, Per 30 Endpoints |
| N1-AM-30-SnS1Y | N1-CloudCampus, Add-On Package, Access Management, Software Subscription and Support, Per 30 Endpoints, 1 Év |
| N1-EPNP-30-Lic | N1-CloudCampus, Add-On Package, Endpoints Plug and Play, Per 30 Endpoints |
| N1-EPNP-30-SnS1Y | N1-CloudCampus, Add-On Package, Endpoints Plug and Play, Software Subscription and Support, Per 30 Endpoints, 1 Év |
| N1-APP-X7FSwitch | N1-CloudCampus, Add-On Package, Intelligent Application Analysis, X7 Series Fixed Switch, Per |
| Device | |
| N1-APP-X7FSwitchSnS1Y | N1-CloudCampus, Add-On Package, Intelligent Application Analysis, X7 Series Fixed Switch, Software Subscription and Support, Készülékenként, 1 Év |
Huawei S6750-H48Y8C Switch Product Applications
