Leírás
DAC QSFP-40G-CU1M offers low power consumption and low latency, making it an ideal solution for short-distance transmission (up to 7m) between data center racks, saving costs compared to a combination of modules and jumpers
DAC QSFP-40G-CU1M Product Overview
This passive Twinax copper cable supports 40 Gigabit Ethernet applications connected through QSFP+ (Mini-GBIC) portok. This copper QSFP+ cable is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
Designed for high-speed performance, this low-power, low-latency QSFP+ cable is a cost-effective alternative to fiber-optic cable assemblies, supporting short-distance applications such as point-to-point in-rack network switch or server connections.
DAC QSFP-40G-CU1M Product Pictures
DAC QSFP-40G-CU1M Product Specifications
| Tétel | Details |
| Modell | QSFP-40G-CU1M |
| Leírás | QSFP+,40G,High Speed Direct-attach Cables,1m,QSFP+38M,CC8P0.254B(S),QSFP+38M,Used indoor |
| Connector X1 | QSFP+ |
| Connector X2 | QSFP+ |
| Cable length [m(ft.)] | 1 m (3.28 ft.) |
| Electrical attribute | Passive |
| Bend radius [mm (ban ben.)] | 35 mm (1.38 ban ben.) |
| Minimum Clearance for Cable Routing [mm (ban ben.)] | 75 mm (2.95 ban ben.) |
| Max Data Rate | 40Gbps |
| Minimum Bend Radius | 35mm |
| Wire AWG | 30AWG |
| Jacket Material | PVC (OFNR) |
| Hőfok | 0 to 70°C (32 to 158°F) |
| Protokollok | 10G/40Gigabit Ethernet, Fiber Channel |
DAC QSFP-40G-CU1M Product Features
- Power Consumption 0.5W
- Tested in Targeted Switches for Superior Performance, Quality, and Reliability
- Minimum Bend Radius 35mm for Flexible Routing
- Simplifies the Patching and Offers a Cost-effective Way for Short Links
- FS BOX – Support Real-time Configuration
- Hot Pluggable QSFP+ MSA Compliant
- Low Insertion Loss and Ultra-low Crosstalk for Improved Performance
- RoHS Compliant
DAC QSFP-40G-CU1M Product and More DAC cables
SFP+ to SFP+ High-Speed Cable
QSFP+ to QSFP+ High-Speed Cable
QSFP+ to 4*SFP+ High-Speed Cable
QSFP28 to QSFP28 High-Speed Cable
QSFP28 to 4*SFP28 High-Speed Cable
Understanding AOC Cables
SFP+ to SFP+ AOC Cable
QSFP+ to QSFP+ AOC cable
QSFP+ to 4*SFP+ AOC cable
QSFP28 to QSFP28 AOC Cable
DAC QSFP-40G-CU1M Product Applications
