Deskripsyon
Quectel EC25-AFDL LCC Module is a LTE Cat 4 module optimized specially for M2M and IoT applications delivering maximum data rates up to 150 Mbps downlink and 50 Mbps uplink
Quectel EC25-AFDL LCC Module Product Overview
Quectel EC25-AFDL LCC Module is a LTE Cat 4 module optimized specially for M2M and IoT applications delivering maximum data rates up to 150 Mbps downlink and 50 Mbps uplink. The module offers a rich set of Internet protocols, entèfas endistri-estanda ak fonksyonalite abondan (USB chofè seri pou Windows 7/8/8.1/10/11, Linux, Android). Se poutèt sa, it allows for flexible migration among them in design and manufacturing. Anplis de sa, EC25 series contains 15 variants: EC25-A, EC25-ADL, EC25-V, EC25-AF, EC25-AFDL(Done-sèlman), EC25-AFX, EC25-AFXD(Done-sèlman), EC25-MX, EC25-AU, EC25-AUX, EC25-J, EC25-EU, EC25-EUX, EC25-E and EC25-EM.
Quectel EC25-AFDL LCC Module Product Pictures
Quectel EC25-AFDL LCC Module Product Specifications
| Mak | Quectel |
| LTE chat 4 | EC25-AFDL(Done-sèlman) |
| Rejyon/Operatè | Amerik di Nò |
| Dimansyon (mm) | 32.0 × 29.0 × 2.4 |
| Tanperati Fonksyònman | -35°C a +75 °C |
| Tanperati pwolonje | -40°C to +85°C |
| LTE-FDD | B2/B4/B5/B12/B13/B14/B66/B71 |
| GNSS | GPS/GLONASS/BDS/Galileo/QZSS (Si ou vle) |
| Carrier | Amerik: Verizon/AT&T(FirstNet)/ |
| T-Mobile/U.S. Selilè | |
| Kanada: Rogers/Telus | |
| Regilasyon | Global: GCF |
| Amerik: FCC | |
| Amerik di Nò: PTCRB | |
| Kanada: IC | |
| Lòt moun | RoHS/WHQL |
| Pousantaj done LTE-FDD (Mbps) | 150 (DL)/ 50 (UL) |
| DC-HSPA+ Pousantaj Done (Mbps) | – |
| Pousantaj done WCDMA (kbps) | – |
| EDGE Pousantaj Done (kbps) | – |
| Pousantaj done GPRS (kbps) | – |
| (U)SIM | x 1 |
| UART | x 2 |
| USB 2.0 | x 1 |
| Audio Digital (PCM) | x 1 |
| 2C | x 1 |
| SDIO | x 2 |
| SGMII | x 1 |
| Wi-Fi | x1 |
| Bluetooth* | x 1 |
| ADC | x 2 |
| Mòd Codec Lapawòl | – |
| Eko Aritmetik | – |
| VoLTE | – |
| DTMF | – |
| DFOTA | ● |
| QMI/ RmNet | ● |
| Audio Playback*/ | Si ou vle |
| Audio Recording* | |
| QuecLocator® | ● |
| QuecFile® | ● |
| (U)Deteksyon kat SIM | ● |
| USB Serial Driver | Windows 7/8/8.1/10/11, |
| Linux 2.6–5.15, Android 4.x–12.x | |
| Chofè GNSS | Android 4.x–12.x |
| Chofè RIL | Android 4.x–12.x |
| USB NDIS chofè | Windows 7/8/8.1/10/11 |
| USB MBIM Driver | Windows 8/8.1/10/11, |
| Linux 3.18–5.15 | |
| USB GobiNet chofè | Linux 2.6–5.15 |
| USB QMI_WWAN chofè | Linux 3.4–5.15 |
| Ranje Voltage ekipman pou | 3.3–4.3 V, 3.8 V Kalite. |
| Konsomasyon pouvwa (Tipik) | 7 μA @ Kouran koupe |
| 0.81 mA @ Dòmi, Typ. | |
| 19.7 mA @ san fè anyen konsa |
Quectel EC25-AFDL LCC Module Product Features
- LTE chat 4 modil
- LCC form factor
- 0mm × 29.0mm × 2.4mm
- 150Lyen desann Mbps / 50Lyen monte Mbps anba LTE
- Ranje tanperati pwolonje nan -40 ° C a + 85 ° C
- LTE chat 4 modil optimize pou aplikasyon M2M ak IoT
- Atravè lemond LTE, UMTS/HSPA(+) ak kouvèti GSM/GPRS/EDGE
- Rafineman karakteristik: sipòte DFOTA ak DTMF
- Teknoloji MIMO satisfè demand pou to done ak fyab lyen nan sistèm kominikasyon modem san fil
Quectel EC25-AFDL LCC Module and More EC25 models
EC25-A LCC Module
EC25-ADL LCC Module
EC25-V LCC Module
EC25-AF LCC Module
EC25-AFDL LCC Module (Done-sèlman)
EC25-AFX LCC Module
EC25-AFXD LCC Module (Done-sèlman)
EC25-MX LCC Module
EC25-AU LCC Module
EC25-AUX LCC Module
EC25-J LCC Module
EC25-E LCC Module
EC25-EU LCC Module
EC25-EUX LCC Module
EC25-EM LCC Module
Quectel EC25-AFDL LCC Module Product Applications
