Huawei S5735-L8T4S-A1 switch

Deskripsyon

Huawei S5735-L8T4S-A1 Switch is simplified gigabit Ethernet switch with 8 x 10/100/1000Base-T pò, 4 x GE SFP ports AC power supply Forwarding performance: 18 Mpps Switching capacity: 24 Gbps/336 Gbps and simplified gigabit Ethernet switches

Huawei S5735-L8T4S-A1 Switch Product Overview

Huawei S5735-L8T4S-A1 Switch is simplified gigabit Ethernet switch with 8 x 10/100/1000Base-T pò, 4 x GE SFP ports AC power supply. Li ideyal pou senaryo tankou aksè nan rezo kanpis antrepriz ak gigabit nan Desktop la. Built on next-generation, high-performance hardware and the Huawei Versatile Routing Platform (VRP), Huawei S5735-L8T4S-A1 outstands with compelling features such as intelligent stack (iStack), fleksib rezo Ethernet, ak divèsifye kontwòl sekirite. Anplis, it supports multiple Layer 3 pwotokòl routage epi bay pèfòmans segondè ak kapasite pwosesis sèvis. Apa de yo, S5735-L8T4S-A1 supports Huawei Easy Operation, a solution that provides zero-touch deployment, replacement offaulty devices without additional configuration, USB-based deployment*, batch device configuration, and batch remote upgrade.The Easy Operation solution facilitates device deployment, ajou, pwovizyon sèvis, ak lòt operasyon jesyon ak antretyen, and also greatly reduces O&M koute.

Huawei S5735-L8T4S-A1 Switch Product Pictures

Huawei S5735-L8T4S-A1 Switch Product Specifications

Mak	Huawei
Modèl	S5735-L8T4S-A1
Pò	8 x 10/100/1000Base-T pò, 4 x GE SFP pò
Wotè chasi [U]	1 U
Pwa san anbalaj [KG(lb)]	1.38 KG (3.04 lb)
Pwa ak anbalaj [KG(lb)]	2.02 KG (4.45 lb)
Konsomasyon pouvwa tipik [W]	21.2 W
Dissipation chalè tipik [BTU/èdtan]	72.34 BTU/èdtan
Maksimòm konsomasyon pouvwa [W]	26.3 W
Dissipation chalè maksimòm [BTU/èdtan]	89.74 BTU/èdtan
MTBF [ane]	71.82 ane
MTTR [èdtan]	2 èdtan
Disponibilite	>0.99999
Bri nan tanperati nòmal (pouvwa acoustic) [dB(A)]	43 dB(A)
Bri nan tanperati nòmal (presyon acoustic) [dB(A)]	31.5 dB(A)
Dimansyon ak anbalaj (H x W x P) [mm(nan.)]	90.0 mm x 370.0 mm x 380.0 mm (3.54 nan. x 14.57 nan. x 14.96 nan.)
Tanperati depo [°C(°F)]	-40°C a +70 °C (-40°F rive +158 °F)
Alontèm opere imidite relatif [RH]	5% pou 95%, san kondansasyon
Altitid opere alontèm [m(ft.)]	0-5000 m (0-16404 ft.)
Altitid depo [m(ft.)]	0-5000 m (0-16404 ft.)
Mòd ekipman pou pouvwa	AC bati-an
Rated vòltaj opinyon [V]	AC antre: 100 V AC pou 240 V AC, 50/60 Hz
Ranje vòltaj Antre [V]	AC antre: 90 V AC pou 290 V AC, 45 Hz pou 65 Hz
Maksimòm opinyon aktyèl [A]	0.8 A
memwa	512 MB
Flash memwa	512 MB
Pò konsole	RJ45
Sèvis pwoteksyon vag pò [kV]	Mòd komen: ± 7 kV
Pwoteksyon vag ekipman pou pouvwa [kV]	± 6 kV nan mòd diferans, ± 6 kV nan mòd komen
Kalite fanatik yo	Bati-an
Tanperati depo [°C(°F)]	-40°C a +70 °C (-40°F rive +158 °F)
Alontèm opere imidite relatif [RH]	5% pou 95%, san kondansasyon
Altitid opere alontèm [m(ft.)]	0-5000 m (0-16404 ft.)
Altitid depo [m(ft.)]	0-5000 m (0-16404 ft.)
Mòd ekipman pou pouvwa	AC bati-an
Rated vòltaj opinyon [V]	AC antre: 100 V AC pou 240 V AC, 50/60 Hz
Ranje vòltaj Antre [V]	AC antre: 90 V AC pou 290 V AC, 45 Hz pou 65 Hz
Maksimòm opinyon aktyèl [A]	0.8 A
memwa	512 MB
Flash memwa	512 MB
Pò konsole	RJ45
Sèvis pwoteksyon vag pò [kV]	Mòd komen: ± 7 kV
Pwoteksyon vag ekipman pou pouvwa [kV]	± 6 kV nan mòd diferans, ± 6 kV nan mòd komen
Kalite fanatik yo	Bati-an
Mòd dissipation chalè	Dissipation chalè ak fanatik, ajisteman vitès fanatik entelijan
Direksyon Airflow	Admisyon lè soti bò gòch ak devan, fatig lè a sou bò dwat
PoE	Pa sipòte
Sètifikasyon	Sètifikasyon EMC
	Sètifikasyon sekirite
	Sètifikasyon fabrikasyon
Dimansyon san anbalaj (H x W x P) [mm(nan.)]	Dimansyon debaz yo (eksepte pati ki soti nan kò a): 43.6 mm x 250.0 mm x 180.0 mm (1.72 nan. x 9.84 nan. x 7.1 nan.)
	Dimansyon maksimòm (pwofondè a se distans ki soti nan pò sou panèl la devan nan pati yo vle pèse anvlòp la soti nan panèl la dèyè): 43.6 mm x 250.0 mm x 187.0 mm (1.72 nan. x 9.84 nan. x 7.36 nan.)
Restriksyon sou pousantaj varyasyon tanperati opere [°C(°F)]	Lè altitid la se 1800-5000 m (5906-16404 ft.), tanperati opere ki pi wo a diminye pa 1 ° C (1.8°F) chak fwa altitid la ogmante pa 220 m (722 ft.).
	Chanjman an pa ka kòmanse lè tanperati anbyen an pi ba pase 0 ° C (32°F).
	Tanperati operasyon an varye ant -5 ° C ak + 45 ° C (23°F rive 113 °F) lè modil optik ak distans transmisyon ki pi gran pase oswa egal a 70 km yo itilize.

Huawei S5735-L8T4S-A1 Switch Product Features

• Huawei S5735-L8T4S-A1 Switch supports intelligent stack (iStack). Teknoloji sa a konbine switch miltip nan yon switch lojik. Manm switch nan yon pil aplike backup redondance pou amelyore fyab aparèy epi sèvi ak agrégation lyen entè-aparèy pou amelyore fyab lyen..
• Huawei S5735-L8T4S-A1 Switch can use the GARP VL .AN Registration Protocol (GVRP) to implement VLAN dynamic distribution, enskripsyon, ak pwopagasyon atribi. GVRP diminye kantite travay konfigirasyon manyèl epi asire konfigirasyon kòrèk.
• Huawei S5735-L8T4S-A1 Switch supports the EasyDeploy function. Espesyalman, Kòmandan an kolekte enfòmasyon an topoloji nan kliyan yo en ak sove enfòmasyon demaraj kliyan ki baze sou topoloji a. Kliyan yo ka ranplase san konfigirasyon. Konfigirasyon ak scripts ka delivre bay kliyan an pakèt. An plis, rezilta livrezon konfigirasyon an ka mande. Kòmandan an kapab tou kolekte epi montre enfòmasyon sou konsomasyon pouvwa sou rezo a tout antye.

Huawei S5735-L8T4S-A1 Switch and more S5735 Models

S5735-L8T4S-QA1 (8*10/100/1000Pò BASE-T, 4*Pò GE SFP, AC pouvwa,Fanless)

S5735-L8P4S-QA1 (8*10/100/1000Pò BASE-T, 4*Pò GE SFP, PoE+, AC pouvwa, Fanless)

S5735-L24T4S-QA1 (24*10/100/1000Pò BASE-T, 4*Pò GE SFP, AC pouvwa, Fanless)

S5735-L24T4X-QA1 (24*10/100/1000Pò BASE-T, 4*10Pò GE SFP+, AC pouvwa, Fanless)

S5735-L8T4S-A1 (8*10/100/1000Pò BASE-T, 4*Pò GE SFP, AC pouvwa)

S5735-L8P4S-A1 (8*10/100/1000Pò BASE-T, 4*Pò GE SFP, PoE+, AC pouvwa)

S5735-L8T4X-A1 (8*10/100/1000Pò BASE-T, 4*10Pò GE SFP+, AC pouvwa)

S5735-L8P4X-A1 (8*10/100/1000Pò BASE-T, 4*10Pò GE SFP+, PoE+, AC pouvwa)

S5735-L24T4S-A1 (24*10/100/1000Pò BASE-T, 4*Pò GE SFP, AC pouvwa)

S5735-L24P4S-A1 (24*10/100/1000Pò BASE-T, 4*Pò GE SFP, PoE+, AC pouvwa)

S5735-L24T4X-A1 (24*10/100/1000Pò BASE-T, 4*10Pò GE SFP+, AC pouvwa)

S5735-L24T4X-D1 (24*10/100/1000Pò BASE-T, 4*10Pò GE SFP+, DC pouvwa)

S5735-L24P4X-A1 (24*10/100/1000Pò BASE-T, 4*10Pò GE SFP+, PoE+, AC pouvwa)

S5735-L48T4S-A1 (48*10/100/1000Pò BASE-T, 4*Pò GE SFP, AC pouvwa)

S5735-L48P4S-A1 (48*10/100/1000Pò BASE-T, 4*Pò GE SFP, PoE+, AC pouvwa)

S5735-L48T4X-A1 (48*10/100/1000Pò BASE-T, 4*10Pò GE SFP+, AC pouvwa)

S5735-L48P4X-A1 (48*10/100/1000Pò BASE-T, 4*10Pò GE SFP+, PoE+, AC pouvwa)

S5735-L12T4S-A (12 x 10/100/1000BASE-T pò, 4 x GE SFP pò, AC pouvwa)

S5735-L12P4S-A (12 x 10/100/1000BASE-T pò, 4 x GE SFP pò, PoE+, AC pouvwa)

S5735-L24T4S-A (24 x 10/100/1000BASE-T pò, 4 x GE SFP pò, AC pouvwa)

S5735-L24P4S-A (24 x 10/100/1000BASE-T pò, 4 x GE SFP pò, PoE+, AC pouvwa)

S5735-L24T4X-A (24 x 10/100/1000BASE-T pò, 4 x 10 Pò GE SFP+, AC pouvwa)

S5735-L24T4X-D (24 x 10/100/1000BASE-T pò, 4 x 10 Pò GE SFP+, DC pouvwa)

S5735-L24P4X-A (24 x 10/100/1000BASE-T pò, 4 x 10 Pò GE SFP+, PoE+, AC pouvwa)

S5735-L48T4S-A (48 x 10/100/1000BASE-T pò, 4 x GE SFP pò, AC pouvwa)

S5735-L48T4X-A (48 x 10/100/1000BASE-T pò, 4 x 10 Pò GE SFP+, AC pouvwa)

S5735-L48P4X-A pake (48 x 10/100/1000BASE-T pò, 4 x 10 Pò GE SFP+, PoE+, 1*1000W PoE AC pouvwa modil)

S5735-L32ST4X-A (24 x GE SFP pò, 8 *10/100/1000Baz-T, 4 x 10 Pò GE SFP+, AC pouvwa)

S5735-L32ST4X-D (24 x GE SFP pò, 8 *10/100/1000Baz-T, 4 x 10 Pò GE SFP+, DC pouvwa)

Huawei S5735-L8T4S-A1 Switch Product Applications
