Deskripsyon
Huawei AR651W-8P Router is an enterprise-class Access Routers (ARs) fèt pou epòk nwaj la ak 2 * GE Combo WAN,8*GE LAN (PoE+),1*USB2.0,802.11b/g/n/ac,2*2MIMO,1*plas MIC
Huawei AR651W-8P Router Product Overview
Huawei AR651W-8P Router is a 1U fixed routers designed for use in small- and medium-sized business (SMBs) and small-sized enterprise branches. The AR650 integrates various service features such as SD-WAN, routage, chanje, sekirite, ak WLAN, providing diversified services and high performance. Anplis de sa, the router offers Built-in firewall, IPS(AR651/AR651W/AR651EW/AR651W-8P/AR657W), URL filtering, Antivirus(AR651/AR651W/AR651EW/AR651W-8P/AR657W) and multiple VPN technologies, providing comprehensive security protection capabil
Huawei AR651W-8P Router Product Pictures
Huawei AR651W-8P Router Product Specifications
| Atik | Detay yo |
| Mak | Huawei |
| Modèl | AR651W-8P |
| Nimewo Pati | 50010492 |
| Premye vèsyon sipòte | V300R019C13 |
| Deskripsyon | 2*GE Combo WAN,8*GE LAN (PoE+),1*USB2.0,802.11b/g/n/ac,2*2MIMO,1*plas MIC |
| Kalite enstalasyon | Rack Bann travay Kont miray la |
| Dimansyon ak anbalaj (H x W x P) [mm(nan.)] | 110 mm x 435 mm x 360 mm (4.33 nan. x 17.13 nan. x 14.17 nan.) |
| Wotè chasi [U] | 1 U |
| Pwa ak anbalaj [KG(lb)] | 2.9 KG (6.37 lb) |
| Pwa san anbalaj [KG(lb)] | 1.92 KG (4.23 lb) |
| CPU | 1.4 GHz, 4 Nwayo |
| memwa | 2 GB |
| NAND Flash | 1 GB |
| Pò konsole | RJ45 |
| RTC | Sipòte |
| Maksimòm konsomasyon pouvwa [W] | 117 W |
| Mòd ekipman pou pouvwa | AC ekstèn |
| Kantite modil pouvwa | 1 |
| Rated vòltaj opinyon [V] | 100 V pou 220 V, 50 Hz/60 Hz |
| Ranje vòltaj Antre [V] | 100 V pou 264 V, 47 Hz pou 63 Hz |
| Maksimòm opinyon aktyèl [A] | 1.5 A |
| Maksimòm pwodiksyon pouvwa [W] | 60 W |
| Kalite fanatik yo | Bati-an |
| Mòd dissipation chalè | Refwadisman lè |
| Direksyon Airflow | Gòch a dwat |
| Fant pwolonje (konfigirasyon estanda) | 1 x MIC |
| Ekipman pou pouvwa redondants | Pa sipòte |
| Antre RPS | Pa sipòte |
| PoE | The GE0 to GE7 interfaces are supported. IEEE 802.3af/IEEE 802.3at |
| PoE power interfaces | 8 |
| PoE+ power interfaces | 8 |
| Bri nan tanperati nòmal (pouvwa acoustic) [dB(A)] | 50 dB(A) |
| Tanperati fonksyònman alontèm [°C(°F)] | 0°C a 45 °C (32°F rive 113 °F) |
| Tanperati depo [°C(°F)] | -40°C a +70 °C (-40°F rive +158 °F) |
| Alontèm opere imidite relatif [RH] | 5% RH pou 95% RH, ki pa kondanse |
| Altitid opere alontèm [m(ft.)] | < 5000 m (16404.2 ft.) |
| MTBF [ane] | 42.06 ane |
| MTTR [èdtan] | 2 èdtan |
| Disponibilite | 0.999994571 |
| Relationship between PoE and system power modules [W] | The PoE power jack connects to a 150 W PoE Power Adapter to provide power for IEEE 802.3af/IEEE 802.3at compliant PDs (such as IP phones, WLAN AP yo, and cameras) connected to GE interfaces of the router. |
| Maximum PoE output power [W] | Total maximum power: 100 W |
| PoE mode: up to six ports, no more than 100 W | |
| PoE+ mode: up to three ports, no more than 100 W | |
| Dimansyon san anbalaj (H x W x P) [mm(nan.)] | Dimansyon debaz yo (eksepte pati ki soti nan kò a): 44.0 mm x 300.0 mm x 220.3 mm (1.73 nan. x 11.81 nan. x 8.67 nan.) |
| Dimansyon maksimòm (pwofondè a se distans ki soti nan pò sou panèl la devan manch lan sou panèl la dèyè): 44.0 mm x 300.0 mm x 229.0 mm (1.73 nan. x 11.81 nan. x 9.02 nan.) |
Huawei AR651W-8P Router Product Features
- Processeurs milti-nwayo ak yon estrikti switch ki pa bloke
- Twa fwa pèfòmans mwayèn endistri a, bay latansi ki pi ba a pou sèvis kle yo
- Lyen backup pou sèvis antrepriz, amelyore fyab
- Deteksyon fay ak detèminasyon an milisgond, minimize tan entèripsyon sèvis yo
- Entegrasyon fonksyon tankou routage, chanje, VPN, sekirite, ak WLAN, satisfè kondisyon divèsifye sèvis antrepriz, ekonomize espas, ak diminye TCO
Huawei AR651W-8P Router and More Models
AR651C AC lame, 10*GE RJ45, 2*GE SFP, 1*USB 3.0
AR651, 2*GE Combo WAN, 8*GE LAN, 1*USB2.0, 1*plas MIC
AR651W, 2*GE Combo WAN, 8*GE LAN, 1*USB2.0, 802.11b/g/n/ac, 2*2MIMO, 1*plas MIC
AR651EW,2*10GE SFP+ WAN,2*GE WAN,8*GE LAN,1*USB2.0,802.11b/g/n/ac/ax,2*2MIMO,1*plas MIC
AR651W-8P,2*GE Combo WAN,8*GE LAN (PoE+),1*USB2.0,802.11b/g/n/ac,2*2MIMO,1*plas MIC
AR657W, 2*GE Combo WAN, 1*VDSL 35B WAN, 8*GE LAN, 1*USB2.0,802.11b/g/n/ac, 2*2 MIMO, 1*plas MIC
Huawei AR651W-8P Router Product Ordering Info
| Konfigirasyon chasi | Deskripsyon |
| NetEngine AR651C | AR651C AC lame, 10*GE RJ45,2*GE SFP, 1*USB, with the AC/DC adapter |
| NetEngine AR651 | AR651,2*GE combo WAN,8*GE LAN,1*USB,1*plas MIC |
| NetEngine AR651W | AR651W,2*GE Combo WAN,8*GE LAN,1*USB,802.11b/g/n/ac,2*2MIMO,1*plas MIC |
| NetEngine AR651EW | AR651EW,2*10GE SFP+,10*GE LAN,1*USB,802.11b/g/n/ac/ax,2*2MIMO,1*plas MIC |
| NetEngine AR651W-8P | AR651W-8P,2*GE Combo WAN,8*GE LAN (PoE+),1*USB,802.11b/g/n/ac,2*2MIMO,1*plas MIC |
| NetEngine AR657W | AR657W,2*GE Combo WAN,1*VDSL 35B WAN,8*GE LAN,1*USB,802.11b/g/n/ac,2*2 MIMO,1*plas MIC |
| E200BMA00 | IEC Box mounting ear (AR650) |
| MIC-1ELTE6-EA | Modil fonksyon, AR, MIC-1ELTE6-EA, WCDMA/LTE FDD/LTE TDD CAT6 kat koòdone |
| MIC-1LTE6-EA | Modil fonksyon, AR, MIC-1LTE6-EA, FDD/TDD/HSPA+/WCDMA CAT6 kat koòdone |
| ASMAM0006 | Omni-direksyon antèn, 698MHz-960MHz/1710MHz-2690MHz,1.0dBi(698MHz-960MHz) &3dBi(1710MHz-2690MHz),10W, SMA-J |
| ASMAM0008 | Antèn izotwòp, 698MHz ~ 960MHz / 1420MHz ~ 2690MHz,2.1dBi(max)(698-960/2110-2170MHz)/4.6dBi(max)(1710-1990/2500-2690MHz), vètikal, Omni,5W,SMA-J,Pa gen Support |
| ARRFSMA0601 | RF Kab Pati,6m, SMA-J,240 Seri,SMA-K |
| LAR0DATAE08 | AR600 Pake Done Valè Te ajoute |
| LAR0SECE08 | AR600 Pake Sekirite Valè Te ajoute |
| LAR0TP1007 | Sèvis Pwoteksyon Menas Abònman 3 Ane (Aplike pou AR650) |
| LAR0PERFE08 | Lisans pèfòmans AR650 |
| LAR0PONE01 | AR600&6100&6200&6300 Pasif Optical Rezo Pake Valè Te ajoute |
| N1-Campus-F-AR600 | N1-CloudCampus (ekskli SD-WAN), Fondasyon, Seri AR600 |
| N1-LANDE-F-AR600 | N1-CloudCampus SD-WAN (enkli SD-WAN), Fondasyon, AR600 |
| N1-LANE-TO-AR600 | N1-CloudCampus SD-WAN (enkli SD-WAN), Avanse, AR600 |
| N1-FToA-AR600 | N1-CloudCampus SD-WAN (enkli SD-WAN), Amelyore Fondasyon an avanse, Seri AR600 |
| N1-APP-AR600 | N1-CloudCampus SD-WAN Add-On, Entelijan analiz aplikasyon, Seri AR600 |
Huawei AR651W-8P Router Product Applications
