SKU: Huawei QSFP-40G-SR4 SFP Kategorija: Oznake: , ,

Opis

Huawei QSFP-40G-SR4 SFP is 40GBase-ER4 Optical Transceiver,QSFP+,40G,Single-mode Module (1310nm,40km,LC)

Huawei QSFP-40G-SR4 SFP Product Overview

Huawei QSFP-40G-SR4 SFP adopts MTP/MPO interface, the working wavelength is 850nm, and is generally used in multimode applications. When it is used with OM3/OM4 multimode optical fiber, the transmission distance is 100 m and 150 m respectively, which is mainly used to realize the connection between network devices in the data center. The 40GBASE-SR4 optical module can not only use MTP/MPO fiber jumpers to connect two 40G network devices, but also can be used with MTP/MPO to LC fiber jumpers to achieve the connection between 40G network devices and 10G network devices.

There are many types of 40G QSFP+ optical modules, including 40GBASE-SR4, 40GBASE-LR4, 40GBASE-ER4, itd.

Huawei QSFP-40G-SR4 SFP Product Pictures

Huawei QSFP-40G-SR4 SFP YCICT Huawei QSFP-40G-SR4 SFP PRICE AND SPECS HUAWEI QSFPHuawei QSFP-40G-SR4 SFP YCICT Huawei QSFP-40G-SR4 SFP PRICE AND SPECS HUAWEI 40G QSFP

Huawei QSFP-40G-SR4 SFP YCICT Huawei QSFP-40G-SR4 SFP PRICE AND SPECS HUAWEI 40G SFPHuawei QSFP-40G-SR4 SFP YCICT Huawei QSFP-40G-SR4 SFP PRICE AND SPECS HUAWEI 40G QSFP

Huawei QSFP-40G-SR4 SFP Product Specifications

Stavka Opis
Faktor forme primopredajnika QSFP+
Brzina prenosa 40GE
Centralna talasna dužina (nm) 850
Usklađenost sa standardima 40GBASE-SR4
Tip konektora MPO/PC (8-pramen ili 12 pramenova, tip B, ženski konektor)
Primjenjivi kabel i maksimalna udaljenost prijenosa Višemodno vlakno (OM3): 0.1 km
Višemodno vlakno (OM4): 0.15 km
Predajna snaga (dBm) -7.6 to +2.4
Maksimalna osjetljivost prijemnika (dBm) -5.4
Snaga preopterećenja (dBm) 2.4
Omjer izumiranja (dB) 3
Radna temperatura 0°C do 70°C (32°F do 158°F)
Broj dijela 02310MHQ

Huawei QSFP-40G-SR4 SFP Product Features

  • Functionally identical to Huawei® QSFP-40G-SR4-HW
  • High Channel Capacity: 40 Gbps per optics
  • Up to 100m links on OM3 MMF or 150m on OM4 MMF
  • High-Reliability 4-channel 850nm VCSEL laser
  • Electrically hot-swappable
  • Compliant with IEEE 802.3ba 40GBASE-SR4
  • Power dissipation < 1.5 W
  • Supports Digital Diagnostics Monitoring
  • RoHS6 Compliant

Huawei QSFP-40G-SR4 SFP Product and More SFP models

QSFP28-100G-SR4 100GBase-SR4 optički primopredajnik,QSFP28,100G,Multi-mode (850nm,0.1km,MPO)
QSFP28-100G-SR4-ISP 100GBase-SR4 optički primopredajnik,QSFP28,100G,Multi-mode (850nm,0.1km,MPO，ISP)
QSFP28-100G-PSM4 100GBase-PSM4 optički primopredajnik,QSFP28,100G,Jednomodni modul (1310nm,0.5km,MPO)
QSFP-100G-SWDM4 100GBase-SWDM4 Optical Transceiver,QSFP+,100GE,Multi-mode Module(850,0.075km-OM3,0.1km-OM4,LC)
QSFP-100G-CWDM4 100GBase-CWDM4 optički primopredajnik,QSFP28,100G,Jednomodni modul (1310nm,2km,LC)
QSFP-100G-CWDM4-ISP 100GBase-CWDM4 optički primopredajnik,QSFP28,100G,Jednomodni modul (1310nm,2km,LC，ISP)
QSFP-100G-eCWDM4 100GBase-eCWDM4 Optical Transceiver,QSFP28,100G,Jednomodni modul (1310nm,10km,LC)
QSFP28-100G-LR4 100GBase-LR4 optički primopredajnik,QSFP28,100G,Single-mode (1310nm,10km,LC)
QSFP-100G-LR4-ISP 100GBase-LR4 optički primopredajnik,QSFP28,100G,Single-mode (1310nm,10km,LC,ISP)
QSFP-100G-ER4-Lite 100GBase-ER4-Lite optički primopredajnik,QSFP28,100G,Jednomodni modul (1310nm,30km(FEC OFF),40km(FEC ON),LC)
CFP-100G-SR10 High Speed Transceiver,CFP,100G,Multimode Module(850nm,10*10G,0.1km,MPO)
CFP-100G-LR4 High Speed Transceiver,CFP,100G,Single-mode Module(1310nm band,4*25G,10km,stright LC)
CFP-100G-ER4 High Speed Transceiver,CFP,100G,Single-mode Module(1310nm band,4*25G,40km,stright LC)
CFP2-100G-SR10 High Speed Transceiver,CFP2,100G,Multimode Module(850nm,10*10G,0.1km,MPO)
CFP2-100G-LR4 High Speed Transceiver,CFP2,100G,Single-mode Module(1310nm band,4*25G,10km,stright LC)
CFP2-100G-ER4 High Speed Transceiver,CFP2,100G,Single-mode Module(1310nm,4*25G,40km,stright LC)
QSFP-40G-iSR4 40GBase-iSR4 optički primopredajnik, QSFP+,40G,Multi-mode (850nm,0.15km,MPO) (povezivanje na jedan QSFP+ ili četiri SFP+)
QSFP-40G-eSR4 40GBase-eSR4 optički primopredajnik, QSFP+,40G,Multi-mode (850nm,0.3km,MPO) (povezivanje na jedan QSFP+ ili četiri SFP+)
QSFP-40G-eSM4 40GBase-eSM4 optički primopredajnik, QSFP+, 40G,Single-mode Module (1310nm,10km,MPO) (povezivanje na jedan QSFP+ ili četiri SFP+)
QSFP-40G-SR-BD 40GBase-BD optički primopredajnik, QSFP+,40G,Multi-mode (850nm,0.1km,LC) QSFP-40G-SDLC-PAM
40GBase-SDLC Optički primopredajnik, QSFP+,40G,Multi-mode(850nm,PAM4,0.1km- OM3,0,15km-OM4,LC)
QSFP-40G-eSDLC-PAM 40GBase-eSDLC optički primopredajnik, QSFP+,40G,Multi-mode(850nm,PAM4,0.1km- OM3,0,3km-OM4,LC)
QSFP-40G-SDLC-PAM-G2 40GBase-SDLC optički primopredajnik, QSFP+,40G,Multi-mode(850nm,PAM4- G2,0,1km-OM3,0,15km-OM4,LC)
QSFP-40G-eSDLCPAM-G2 40GBase-eSDLC optički primopredajnik, QSFP+,40G,Multi-mode(850nm,PAM4- G2,0,1km-OM3,0,3km-OM4,LC)
QSFP-40G-LR4-Lite 40GBase-LR4 Lite optički primopredajnik,QSFP+,40G,Single-mode Module(1310nm,2km,LC)
QSFP-40G-LR4 40GBase-LR4 optički primopredajnik,QSFP+,40GE,Single-mode Module(1310nm,10km,LC)
QSFP-40G-ER4 40GBase-ER4 optički primopredajnik,QSFP+,40G,Single-mode Module (1310nm,40km,LC)
SFP-25G-SR 25GBase-SR Optical Transceiver-SFP28-25G Multi-mode(850nm,0.1km,LC)
SFP-10G-USR 10GBase-USR Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.1km,LC)
OSXD22N00 Optički primopredajnik,SFP+,10G,Multi-mode Module(1310nm,0.22km,LC,LRM)
OMXD30000 Optički primopredajnik,SFP+,10G,Multi-mode Module(850nm,0.3km,LC)
SFP-10G-iLR Optički primopredajnik,SFP+,9.8G,Single-mode Module(1310nm,1.4km,LC)
SFP-10G-LR Optički primopredajnik,SFP+,10G,Single-mode Module(1310nm,10km,LC)
OSX040N01 Optički primopredajnik,SFP+,10G,Single-mode Module(1550nm,40km,LC)
SFP-10G-ZR 10GBase-ZR Optical Transceiver,SFP+,10G,Single-mode Module(1550nm,80km,LC)
SFP-10G-ZDWT-L Optički primopredajnik,SFP+,10G,Single-mode Module(DWDM,1560.61-1529.16nm,60km,LC)
SFP-10G-BXU1 10GBase,BIDI Optical Transceiver,SFP+,10G,Single-mode Module(TX1270nm/RX1330nm,10km,LC)
SFP-10G-BXD1 10GBase,BIDI Optical Transceiver,SFP+,10G,Single-mode Module(TX1330nm/RX1270nm,10km,LC)
SFP-10G-ER-SM1330-BIDI Optički primopredajnik,SFP+,10G,BIDI Single-mode Module(TX 1330nm/RX 1270nm,40km,LC)
SFP-10G-ER-SM1270-BIDI Optički primopredajnik,SFP+,10G,BIDI Single-mode Module(TX 1270nm/RX 1330nm,40km,LC)

Huawei QSFP-40G-SR4 SFP Product Applications
