Opis
Huawei AP8050DN is the latest-generation 802.11ac wave 2 outdoor access points (AP), which supports 2X2 MU-MIMO and two spatial streams, offering high flexibility with IEEE 802.11a/b/g/n/ac compliance.
Huawei AP8050DN Product Overview
Huawei AP8050DN offers services simultaneously on 2.4 GHz i 5 GHz radios to connect more users, and supports wireless bridging, built-in Bluetooth(BLE4. 1). Stoga, it provides gigabit access for wireless users. AP8O50DN provides comprehensive service support capabilities and feature high reliability, high security, simple network deployment, automatic Access Controller (AC) discovery and configuration, and real-time management and maintenance, which meet outdoor network requirements. The product is recommended for use in coverage scenarios (na primjer, high-densitystadiums, kvadrata, pešačke ulice, i zabavnim parkovima) and bridging scenarios (na primjer, wireless harbors, data backhaul, video backhaul, and train-to-ground backhaul)
Huawei AP8050DN Product Pictures
Huawei AP8050DN Product Specifications
| Specifikacije | AP8050DN |
| Dimenzije (V x Š x D) | 100 mm x 220 mm x 220 mm |
| Power Input | PoE napajanje: In compliance with IEEE 802.3 at |
| Maksimalna potrošnja energije | AP8050DN: 18W |
| AP8150DN: 18W | |
| Radna temperatura | –40°C do +65°C |
| Antenna Type | AP8050DN: Built-in directional antennas |
| AP8150DN: Vanjske antene | |
| Maximum Number of Concurrent Users | ≤ 512 |
| Maximum Transmit Power | AP8050DN: |
| – 2.4G: 27 dBm (kombinovana snaga) | |
| – 5G: 26 dBm (kombinovana snaga) | |
| AP8150DN: | |
| 2.4G: 27 dBm (kombinovana snaga) | |
| 5G: 24 dBm (kombinovana snaga) | |
| MIMO: Spatial Streams | 2 x 2:2 |
| Radio Protocols | 802.11a/b/g/n/ac/ac Wave 2 |
| Maksimalna stopa | AP8050DN: 1.267 Gbit/s |
| AP8150DN: 1.73 Gbit/s |
Huawei AP8050DN Product Features
- Dual-5G radio technology
AP8050DN can switch from the 2.4 GHz frequency band to the 5 GHz frekvencijski opseg. When working at dual 5 GHz frequency bands simultaneously, the AP provides a system rate of 1.73 Gbit/s and a 20% higher concurrency rate. Osim toga, it can function as a relay APto implement wireless bridging functions, which reduces costs by 50%.
- High-level protection
AP8050DN has built-in 5 kA feeder surge protectors and require no external surge protective devices, which simplifies installation and lowers costs. They use a metal shell, waterproof connectors, and an overall heat dissipation design, and provide IP68 dustproof and water proof protection to ensure stable and reliable operations.
- Cloud-based management
Huawei Cloud Managed Network (CMN) Solution consists of the cloud management platform and a full range of cloud managed network devices. The cloud management platform provides various functions including management of APs, tenants, aplikacije, and licenses, network planning and optimization, device monitoring, network service configuration, and value-added services.
Huawei AP8050DN Product Applications
