Huawei SFP EPONOLT PRX30 10G is asymmetrical 10GEPON ONU PRX30 SFP+ Optical Transceiver for Huawei OLT equipment
Huawei SFP EPONOLT PRX30 10G Product Overview
Huawei SFP EPONOLT PRX30 10G is Bidirectional SFP + transceiver for 10G / 1G Asymmetric EPON (তাকে) equipped with high power 1310nm DFB laser for transmission (1.25জিবিপিএস, 1577nm) and high sensitivity 1577nm APD for reception ( 10.3125 Gbs). The Maximum range reaches 20km on an SMF fiber with 3.3 Volts power supply.
Huawei SFP EPONOLT PRX30 10G Product Pictures
Huawei SFP EPONOLT PRX30 10G Product Specifications
| Transmitter Optical Characteristics | |||||
| প্যারামিটার | Symbol | মিন. | টাইপ. | সর্বোচ্চ. | Unit |
| Average Launch Optical | Pout | 0.62 | 5.62 | dBm | |
| শক্তি | |||||
| বিলুপ্তির অনুপাত | ER | 9 | dB | ||
| Wavelength Center | λ | 1290 | 1310 | 1330 | nm |
| Spectral Width (-20dB) | Δλ | 1 | nm | ||
| Side Suppression Mode | SMSR | 30 | dB | ||
| Fashion | |||||
| Burst on time | Your | 30 | এনএস | ||
| Burst off time | Toff | 30 | এনএস | ||
| Transmitter and | TDP | 1.4 | dB | ||
| dispersion penalty | |||||
| Eye Diagram | Compliant With IEEE Std 802.3ah ™ -2004 | ||||
Huawei SFP EPONOLT PRX30 10G Product Features
- Single fiber Bidi data links Asymmetric Tx1.25Gbps / Rx10.3125Gbps application
- 0 প্রতি 70 ° C operating case temperature
- একক 3.3V পাওয়ার সাপ্লাই
- এসএফপি + package with SC Receptacle connector
- Hot-pluggable capability
- High power 1310nm DFB LD and high sensitivity 1577nm APD
- Support 20km transmission distance with SMF
- CML compatible data input / output interface
- Low power dissipation
- Digital diagnostic monitor interface
- 8 ETH SFP ports that support 10GE/GE optical modules
- Line clock used as the system clock
- সর্বাধিক 80 Gbit/s non-convergence upstream bandwidth
- Ethernet clock synchronization
- Temperature query and high temperature alarm
- Automatic power shutdown in case of a high temperature
Huawei SFP EPONOLT PRX30 10G And more Related SFP
Huawei SFP EPONOLT PRX30 10G Product Applications
