Beskrywing
Huawei S5720-50X-EI-DC Switch is an Enhanced Gigabit Switch with 46 Ethernet 10/100/1000 hawens, 4 10 Gig SFP+, 2 QSFP+ dedicated stack ports and AC or DC power supply, supporting RPS, power socket on the front panel
Huawei S5720-50X-EI-DC Switch Product Overview
Die skakelaar bied aanstuurprestasie: 129 Mpps en skakelvermoë: 598 Gbit/s. It provides flexible all-gigabit access and enhanced 10GE uplink port scalability. Huawei S5720-50X-EI-DC is widely used as access/aggregation switches in enterprise campus networks or gigabit access switches in data centers. Daarby, the switch provides excellent QoS capabilities and supports queue scheduling and congestion control algorithms. Bowendien, it adopts innovative priority queuing and multi-level scheduling mechanisms to implement fine-grained scheduling of data flows, meeting service quality requirements of different user terminals and services. S5720-EI also provides a series of mechanisms to defend against DoS and user-targeted attacks. DoS-aanvalle is gerig op skakelaars en sluit SYN-vloed in, Land, Smurf, en ICMP-vloedaanvalle. Gebruikergerigte aanvalle sluit vals DHCP-bedieneraanvalle in, IP/MAC-adres spoofing, DHCP versoek vloed, and change of the DHCP CHADDR value
Huawei S5720-50X-EI-DC Switch Product Pictures
Huawei S5720-50X-EI-DC Switch Product Specifications
Item | Beskrywing |
Model | S5720-50X-EI-DC |
Onderdeel nommer | 02350NHD |
Port | 46 Ethernet 10/100/1000 hawens, 4 10 Gig SFP+, 2 QSFP+ dedicated stack ports |
Geheue (RAM) | 2 GB |
Flits | 512 MB in total. Om die beskikbare flitsgeheuegrootte te sien, voer die vertoonweergawe-opdrag uit. |
Gemiddelde tyd tussen mislukkings (MTBF) | 74.31 jare |
Gemiddelde tyd om te herstel (MTTR) | 2 |
Beskikbaarheid | > 0.99999 |
Dienspoort-oorspanningbeskerming | Algemene modus: ±6 kV |
Stroomtoevoerbeskerming | ±1 kV in differential mode, ±2 kV in common mode |
Gewig (met verpakking) | 4.7 kg (10.36 lb) |
Stapel poorte | Two fixed QSFP+ stack ports on the rear card |
RTC | Ondersteun |
RPS | Ondersteun |
PoE | Nie ondersteun nie |
Gegradeerde spanningsreeks | -48 V DC aan -60 V DC |
Maksimum spanningsreeks | -36 V DC aan -72 V DC |
Maksimum kragverbruik (100% deurset, volle spoed van ondersteuners) | 55.3 W |
Werkstemperatuur | 0°C tot 45 °C (32°F tot 113°F) op 'n hoogte van 0-1800 m (0-5906 ft.) |
Stoor temperatuur | -40°C tot +70°C (-40°F tot +158°F) |
Geraas onder normale temperatuur (27°C, klank krag) | < 49.3 dB(A) |
Relatiewe humiditeit | 5% aan 95%, nie-kondenserend |
Bedryfshoogte | 0-2000 m (0-6562 ft.) |
Sertifisering | EMC-sertifisering |
Veiligheid sertifisering | |
Vervaardiging sertifisering | |
Afmetings (H x B x D) | Basiese afmetings (uitgesluit die dele wat uit die liggaam uitsteek): 43.6 mm x 442.0 mm x 224.9 mm (1.72 in. x 17.4 in. x 8.85 in.) |
Maksimum afmetings (die diepte is die afstand van poorte op die voorpaneel na die dele wat by die agterpaneel uitsteek): 43.6 mm x 442.0 mm x 229.9 mm (1.72 in. x 17.4 in. x 9.05 in.) |
Huawei S5720-50X-EI-DC Switch Product Features
- Oop programmeerbaarheidstelsel (OPS) is 'n oop programmeerbare stelsel gebaseer op die Python-taal. IT-administrateurs kan die O&M functions of a switch through Python scripts to quickly innovate functions and implement intelligent O&M.
- S5720-EI uses the mature, stable VRP software platform and supports IPv4/IPv6 dual stacks, IPv6-roeteringsprotokolle (RIPng, OSPFv3, BGP4+, and IS-ISv6), en IPv6 oor IPv4 tonnels (handleiding ingesluit, 6-tot-4, en ISATAP-tonnels). Met hierdie IPv6-kenmerke, the S5720-EI can be deployed on a pure IPv4 network, 'n suiwer IPv6-netwerk, of 'n gedeelde IPv4/IPv6-netwerk, help om IPv4-na-IPv6-oorgang te bereik.
- S5720-EI provides a series of mechanisms to defend against DoS and user-targeted attacks. DoS-aanvalle is gerig op skakelaars en sluit SYN-vloed in, Land, Smurf, en ICMP-vloedaanvalle. Gebruikergerigte aanvalle sluit vals DHCP-bedieneraanvalle in, IP/MAC-adres spoofing, DHCP versoek vloed, and change of the DHCP CHADDR value.
Huawei S5720-50X-EI-DC Switch Product and More S5720-EI Models
S5720-32P-EI-AC 24 Ethernet 10/100/1000 hawens, 4 100/1000 SFP, 4 Gig SFP, 2 QSFP+ dedicated stack ports AC power supply
S5720-32X-EI-AC 24 Ethernet 10/100/1000 hawens, 4 100/1000 SFP, 4 10 Gig SFP+, 2 QSFP+ dedicated stack ports AC or DC power supply
S5720-32X-EI-24S-AC 24 Gig SFP, 4 Ethernet 10/100/1000 hawens, 4 10 Gig SFP+, 2 QSFP+ dedicated stack ports AC or DC power supply
S5720-32X-EI-24S-DC 24 Gig SFP, 4 Ethernet 10/100/1000 hawens, 4 10 Gig SFP+, 2 QSFP+ dedicated stack ports AC or DC power supply
S5720-36C-EI-28S-AC 28 Gig SFP, 4 of which are dual-purpose 10/100/1000, 4 10 Gig SFP+ Double hot swappable AC or DC power supplies
S5720-36C-EI-28S-DC 28 Gig SFP, 4 of which are dual-purpose 10/100/1000, 4 10 Gig SFP+ Double hot swappable AC or DC power supplies
S5720-36C-EI-AC 28 Ethernet 10/100/1000 hawens, 4 of which are dual-purpose 10/100/1000 of SFP, 4 10 Gig SFP+ Double hot swappable AC or DC power supplies, one AC power module equipped by default
S5720-36C-PWR-EI-AC 28 Ethernet 10/100/1000 PoE+ poorte, 4 of which are dual-purpose 10/100/1000 of SFP, 4 10 Gig SFP+ PoE+ Double hot swappable AC or DC power supplies, one AC power module equipped by default
S5720-36PC-EI-AC 28 Ethernet 10/100/1000 hawens, 4 of which are dual-purpose 10/100/1000 of SFP, 4 Gig SFP Double hot swappable AC or DC power supplies, one AC power module equipped by default
S5720-50X-EI-AC 46 Ethernet 10/100/1000 hawens, 4 10 Gig SFP+, 2 QSFP+ dedicated stack ports AC or DC power supply
S5720-50X-EI-DC 46 Ethernet 10/100/1000 hawens, 4 10 Gig SFP+, 2 QSFP+ dedicated stack ports AC or DC power supply
S5720-50X-EI-46S-AC 46 Gig SFP, 4 10 Gig SFP+, 2 QSFP+ dedicated stack ports AC or DC power supply
S5720-50X-EI-46S-DC 46 Gig SFP, 4 10 Gig SFP+, 2 QSFP+ dedicated stack ports AC or DC power supply
S5720-52X-EI-AC 48 Ethernet 10/100/1000 hawens, 4 10 Gig SFP+, 2 QSFP+ dedicated stack ports AC power supply
S5720-52P-EI-AC 48 Ethernet 10/100/1000 hawens, 4 Gig SFP, 2 QSFP+ dedicated stack ports AC power supply
S5720-56C-EI-48S-AC 48 Gig SFP, 4 10 Gig SFP+ Double hot swappable AC or DC power supplies, one AC or DC power module equipped by default
S5720-56C-EI-48S-DC 48 Gig SFP, 4 10 Gig SFP+ Double hot swappable AC or DC power supplies, one AC or DC power module equipped by default
S5720-56C-EI-AC 48 Ethernet 10/100/1000 hawens, 4 10 Gig SFP+ Double hot swappable AC or DC power supplies, one AC or DC power module equipped by default
S5720-56C-EI-DC 48 Ethernet 10/100/1000 hawens, 4 10 Gig SFP+ Double hot swappable AC or DC power supplies, one AC or DC power module equipped by default
S5720-56C-PWR-EI-AC 48 Ethernet 10/100/1000 PoE+ poorte, 4 10 Gig SFP+ PoE+ Double hot swappable AC or DC power supplies, one AC or DC power module equipped by default
S5720-56C-PWR-EI-AC1 48 Ethernet 10/100/1000 PoE+ poorte, 4 10 Gig SFP+ PoE+ Double hot swappable AC or DC power supplies, one AC or DC power module equipped by default
S5720-56C-PWR-EI-DC 48 Ethernet 10/100/1000 PoE+ poorte, 4 10 Gig SFP+ PoE+ Double hot swappable AC or DC power supplies, one AC or DC power module equipped by default
S5720-56PC-EI-AC 48 Ethernet 10/100/1000 hawens, 4 Gig SFP Double hot swappable AC or DC power supplies, one AC power module equipped by default
Huawei S5720-50X-EI-DC Switch Product Applications
