Cisco C9200CX-8P-2XGH-A Switch

Beskrywing

Cisco C9200CX-8P-2XGH-A Switch is a next generation compact, ondernemingsklas, access layer switch with 8-port 1G, 2x10G en 2x1G, PoE+, Netwerkvoordeel

Cisco C9200CX-8P-2XGH-A Switch Product Overview

The switch delivers up to 128 Gbps of switching capacity, met tot 95 Mpps of forwarding performance. It provides nonblocking 1 Gigabit Ethernet (1G) speeds (10/100 Mbps to 1 Gbps) over PoE+ capable copper ports, and nonblocking multigigabit (mGig) speeds (10/100 Mbps to 1GB/2.5GB/5GB/10GB) over 802.3bt Type 3 Klas 6 60W UPOE copper ports. With the same rich feature set as the other models in the Catalyst® 9200 reeks, these fanless switches are sold in various configurations, insluitend slegs data, Krag oor Ethernet Plus (PoE+), en 802.3bt Tipe 3 Klas 6 60W UPOE modelle. They deliver exceptional table scales (MAC/route/ACL) and buffering capabilities for enterprise applications.
Cisco Catalyst 9200CX-modelle bestaan ​​uit vaste-konfigurasie skakelaars met hitte wat na die bokant versprei, gaan na die skakelaar se ingeboude heatsink. Hulle is gebaseer op die Cisco Unified Access® Data Plane 2.0 mini (UADP) argitektuur, wat nie net jou belegging beskerm weens buigsame en programmeerbare pyplyne nie, maar ook 'n groter skaal en hoër deurset toelaat.

Cisco C9200CX-8P-2XGH-A Switch Product Pictures

Cisco C9200CX-8P-2XGH-A Switch Product Specifications

Cisco C9200CX-8P-2XGH-A Switch Product Features

• Flexible downlink options with data, PoE+, POUS, UPOE with mGig for Wi-Fi 6/6E.
• Operational efficiency with optional backplane stacking, supporting stacking bandwidth up to 160 Gbps.
• UADP 2.0 Mini with integrated CPU offers customers optimized scale with better cost structure.
• Enhanced security with AES-128 MACsec encryption on C9200 and AES-256 MACsec encryption for C9200CX models, policy-based segmentation, and trustworthy solutions for the whole Catalyst 9200 Reeks.
• Prop en speel (PnP) aangeskakel: 'n Eenvoudige, veilig, verenig, en geïntegreerde aanbieding om die ontplooiing van nuwe tak- of kampustoestelle of opdaterings aan 'n bestaande netwerk te vergemaklik.
• Cisco IOS XE: 'n Algemene lisensie-gebaseerde bedryfstelsel vir die onderneming Cisco Catalyst 9000 produkfamilie met ondersteuning vir modelgedrewe programmeerbaarheid en stroomtelemetrie.

Cisco C9200CX-8P-2XGH-A Switch and More Models

Cisco C9200CX-8P-2XGH-A Switch Product Applications
